Free Space

Free Space Lasers Overview

Free Space laser diodes and lasers that are available in Pulsed or CW operation

These free space lasers have a variety of output powers and a broad range of wavelengths. For the pulsed lasers, they have pulse widths in femtosecond to nanosecond depending on the application’s needs.

Filters Reset

Type

Wavelength Selection

Power Selection

Mode

Output

Narrow Linewidth

Series

Manufacturer

704 results found

Matchbox Series

R1Z4-Matchbox Laser

The Matchbox series of compact laser diode and DPSS laser modules are available in wavelengths from 405nm thru 1064nm. Options include collimated beam or fiber coupled output, and single mode and multimode versions.

Unik Series

UnikLaser Solo-780.24 QT

The Unik series of CW single-frequency lasers, featuring the Solo and Duetto configurations, are available at a variety of wavelengths with high average powers, making them well suited for a variety of highly specialized scientific and industrial applications. BRaMMS Technology® enables superior performance, high output powers, and outstanding beam properties in an overall compact footprint. The Unik Lasers Solo and Duetto series are utilized in a range of applications including holography, metrology, spectroscopy, and quantum technology.

EP Series

EP2108-DM-B: 2108nm DM Laser Diode 1950-2150nm

The EP series is a tunable single-frequency diode laser available in wavelengths from 1270nm thru 2300nm. Utilizing Eblana’s proprietary discrete-mode (DM) technology ensures excellent side mode suppression ratio (SMSR), without the mode hops inherent to most distributed feedback (DFB) lasers.

DX1 Series

EP2051-DM-DX1

The DX1 series is a tunable single-frequency diode laser in a compact turnkey laser system available in wavelengths from 1270nm thru 2300nm. Utilizing Eblana’s proprietary discrete-mode (DM) technology ensures excellent side mode suppression ratio (SMSR), without the mode hops inherent to most distributed feedback (DFB) lasers.

HL Series

TG420

The HL Series of laser diodes are available in a wide range of wavelengths from violet to red and infrared in support of a broad range of applications. These applications include display, medical, biosciences, industrial tools (sensor, leveler), machine vision, scanners, printers and a myriad of other applications being developed in the industry.

JDL Series

JDL-BAB-75-62-808-TE-200-1.0

The JDL Series of unmounted laser diode bars are available in CW or QCW configurations in wavelength from 760nm – 1064nm. Various emitter configurations and cavity lengths are available offering up to 200W CW and 500W QCW output powers.

JenLas D2

Jenoptik Jenlas D2.mini 2/3/5/8W

The JenLas D2 series of CW disk lasers with a wavelength of 532nm are available with up to 8W output power. These Nd:YVO4 or Yb:KYW solid state lasers are ideal for industrial micro material processing and medical treatments

JOLD-Open Heatsinks Series

The JOLD-Open Heatsinks Series are high quality high power laser diode bar products. They are available in a range of open heatsinks including the CS, CN, and LK package. And in wavelengths from 780nm – 1064nm.

JOLD-Stacks Series

JOLD-450-QAFN-5A: Laser Diode Stack w/ FAC

The JOLD-Stacks Series of high quality high power laser diode bar stacks. They are available with actively (microchannel) cooled or conductively cooled. And in wavelengths from 780nm – 1064nm.

LXCc Series

R2Z3-L4Cc Combiner

The LXCc series is the most compact and flexible all-in-one multicolor laser combiner, with up to 7 laser lines, and up to 500mW output power per line. The turnkey or OEM versions allow a large choice of lasers from 375nm up to 1064nm. The extension module provides the ultimate level of flexibility with up to 4 optical fiber outputs, integrated fast switching output ports for FRAP, or adjustable split power for light-sheet microscopy.

LaserBoxx Low Noise Series

The LaserBoxx low noise Series is a CW diode laser module in a variety of diode wavelengths from 375 to 785nm, with output powers up to 350mW. This compact, self-contained laser module is available in turn-key or OEM versions and utilizes a proprietary alignment-free, monolithic resonator, and comes standard with a graphic user interface with remote diagnostics via USB, RS232, or direct I/O interface.

LaserBoxx HPE Series

The LaserBoxx HPE series is a high power laser diode module offering excellent performance and reliability in a compact driver integrated laser head (Industry-standard compact package). It comes in free space multimode elliptical beam or with removable MM fiber coupling.

LaserBoxx SLM Series

The LaserBoxx-SLM Series is a single longitudinal mode (SLM) CW diode laser module available in wavelengths at 633nm, 785nm, and 830nm delivering ultra-narrow linewidths thanks to its excellent temperature stability and low noise current. The Oxxius proprietary, embedded firmware locks the laser on the same mode at each startup. This compact, self-contained laser module is available in turn-key or OEM versions and utilizes a proprietary alignment-free, monolithic resonator, and comes standard with a graphic user interface with remote diagnostics via USB, RS232, or direct I/O interface.

LDX Series

R1Z8-LDX-3215-735: 735nm Multimode Laser Diode

The LDX Series of high power multimode single emitter laser diodes include wavelengths of 400nm – 1900nm. Available in a wide range of output powers and package types.

LDX-Bar Series

R1Z8-LDX-4319-795: Laser Diode Bar Package

The LDX-Bar Series of multimode laser diode bars packaged on the industry standard CS package. Wavelengths in the red and IR are available and the output power range from 10W to 100W.

LGK Series

LGK 7785-100/150/200/250: 543nm Ultra-Reliable He-Ne Laser Modules

The LGK Series of Gas Lasers include a wide range of HeNe and Argon lasers with wavelengths at 488nm, 515nm, 543nm, 594nm, and 633nm.

LTC-ISB2 Series

R1Z9-LTC-ISB2

The LTC-ISB2 (Integrated Spectral Bench) series from Luxmux, is a broadband multi-wavelength light source that combines up to 6 light sources into a single spectrum product. The system provides individual control of the light sources through a digitally controlled interface. The ISB is a highly integrated solution offering exceptional operational control in a fully self-contained module. Custom, powerful and compact, the ISB is well positioned for integration into a variety of sensing and measurement applications.

LTC-OSE Series

R1Z6-LTC-OSE-1265-1605: BeST-SLED 1300nm 1340nm 1390nm 1430nm 1480nm 1550nm

The LTC-OSE series from Luxmux, trade named BeST-SLED®, can be configured with up to 6 super luminescent diodes and driver circuitry, into a single 32 pin butterfly package. This reliable, cost-effective, rugged broadband light source produces overlapping spectral coverage from 1230nm to 1730nm, generating up to 19 spectral combinations, and average powers up to 50mW. The LCT-OSE series is suitable for direct integration into existing OEM products for Optical Coherence Tomography, Optical Sensing, White Light Interferometry and others.

QCL Series

mirSense Product Family

The QCL series is a high power pulsed Quantum Cascade Laser based on proprietary technology which incorporates high-powered diodes (typically watt-level) emitting in the main transmission bands of the atmosphere (4.0µm, 4.6µm, 4.8µm, 9.x µm). The ITAR free MirSense technology exhibits outstanding performance in terms of power and wall-plug efficiency. This high-performance QCL laser assembly takes full advantage of MirSense’s state of the art technologies.

R Series

The R series of wavelength stabilized single mode and multimode laser diodes offer narrow wavelength spectrum in wavelengths from 633nm thru 1064nm. Package options range from components as basic as a TO-56 or 14-pin BF packaged diodes, to OEM modules including electronics, to UL/CE and IEC certified turn-key systems.

RHAML Series

The RHAML series of diode laser modules deliver a uniform, stable output beam that crucual for machine vision applcations, especially in 3D vision systems. The compact, RHAML series is a reliable light source that incoroporates a fucusing lens that can be easily adjusted by the user. Additionally, the RHAML series is fully IP67 compliant, making it an ideal solution for use in harsh environmental conditions and production/industrial facilities.

RML Series

The RML series of laser diode modules are available with single mode fiber outputs with a set wavelength from 405nm – 2500nm. The compact RML series is available with up to 80mW of output power in a package measuring 15mm in diameter and 40mm in length (without connector) . As an option these modules are offered with a potentiometer for power adjustment, external TTL modulation up to 1MHz and analog modulation up to 100kHz.

SM Series

The SM Series of high power single mode laser diodes in wavelengths of 795nm – 1064nm, are available in a wide range of output powers up to 450mW and package types ranging from chip on submount to fiber coupled butterfly package.

TG Series

R1Z5-TG420

The TG Series of laser diodes emit in the spectral range from 420nm up to 460 nm with a typical output power of 50mW and an absolute maximum output power of 100mW. Assembled in a 5.6 mm (TO-56) packages the TG series is a suitable for a wide range of OEM applications that require blue/violet light.

VD Series

VD-0940I-004W-1C-2A0: 940nm VCSEL Diode

The VD Series of Vertical Cavity, Surface Emitting Laser (VCSEL) emitters, and arrays are available in a wide range of output powers in wavelengths of 850nm and 940nm.  Standard options include VCSEL, VCSEL w/ Diffusor, VCSEL & PD w/ Diffusor, and pulsed VCSELs.  These low-cost lasers are ideal for a wide range of consumer products.

WSLD Series

WSLD-980-001-2-PD

The WSLD series of laser diodes, from WaveSpectrum, are available in a wide range of wavelengths, power levels, and packages. The WSLD wavelength options span from 405nm to 1920nm, with output powers in the range of 20mW to several watts, packaged in standard C, E, and H-Mount packages, as well as a variety of TO-can options.
