1064nm Lasers

What are 1064nm Lasers?

1064nm IR Laser Diodes with Diode Pumped Solid State (DPSS) or Continuous Wave (CW) technology.

IR laser diodes are available with both single-mode and multi-mode beam profiles. They have either free space or fiber coupled outputs. The diode laser packages are ideal for OEM applications, and laser modules are available for either OEM or plug and play applications.

Filters Reset

Type

Power Selection

Energy Selection

Pulse Width Selection

Mode

Output

Linewidth

Series

Manufacturer

Picture Part Number Type Output power (W) Mode Output Linewidth Pulse energy (uJ) Pulse width Rep rate
1064L-2XB: 1064nm Laser (SLM DPSS; MATCHBOX 2) 1064L-1XB CW DPSS Lasers 0.025, 0.300, 0.400, 0.500 Single-Mode Lasers, Multimode Free Space, MM Fiber, SM Fiber, PM Fiber, SMA Port
1064L-2XB: 1064nm Laser (SLM DPSS; MATCHBOX 2) 1064L-2XB CW DPSS Lasers 0.200, 0.300, 0.400 Single-Mode Lasers, Multimode Free Space, MM Fiber, SM Fiber, PM Fiber Narrow
Aero-1064 Pulsed DPSS Lasers 5.0, 10.0 50000.0, 100000.0, 200000.0 20ns Single Shot to 50Hz, Single Shot to 100Hz
AIRTRAC-LD AIRTRAC-LD Pulsed DPSS Lasers, Mil-Spec Lasers 1.0 50000.0 10ns - 25ns 7-21Hz
ALCOR 5W: 1064nm Ultra-Compact Femtosecond Laser ALCOR 10XX Pulsed DPSS Lasers, Pulsed Fiber Lasers, Ultrafast Lasers 2.0, 5.0 0.025, 0.062 100fs, 110fs 80MHz (Optional: 40MHz)
Antares Antares Pulsed DPSS Lasers, Pulsed Fiber Lasers, Ultrafast Lasers 10.0, 20.0, 30.0 0.125, 0.250, 0.375, 0.500 10ps 80MHz
R0Z2-Image-Compact-Efficient-UV-Laser CEUV Series Pulsed DPSS Lasers 5.0, 10.0, 20.0 500.0, 1000.0, 2000.0 3ns 10kHz to 1MHz
DIADEM Series Diadem IR Pulsed DPSS Lasers, Ultrafast Lasers 10.0, 20.0, 30.0 10.0, 20.0, 30.0, 40.0 400fs, 10ps Single shot to 2MHz
LBX-1064 LD Module 0.200 Single-Mode Lasers Free Space, MM Fiber, SM Fiber, PM Fiber
LCX-1064S CW DPSS Lasers 0.100, 0.200, 0.300, 0.500 Single-Mode Lasers Free Space, MM Fiber, SM Fiber, PM Fiber Narrow
Single Emitter LDX-XXXX-1064 Single Emitter 1.5, 3.0, 5.0 Multimode Free Space, MM Fiber
neoMOS neoMOS Pulsed DPSS Lasers 5.0, 15.0, 50.0, 75.0, 100.0 250.0, 400.0, 500.0 600fs, 700fs, 900fs, 10ps, 40ps, 70ps, 100ps Single shot to 80MHz
neoVAN - DPSS Amplifier neoVAN DPSS Amplifiers 50.0 5000.0 400ps, CW
NPS-1064 Pulsed DPSS Lasers, Ultrafast Lasers 0.050, 5.0, 10.0 0.125, 0.250 7ps 40MHz
Onda 1064nm Onda 1064nm Pulsed DPSS Lasers 15.0 800.0 2ns - 12ns Single Shot to 100kHz
Nanosecond DPSS laser Quantas-Q-SPARK-1064 Pulsed DPSS Lasers 0.010 10000.0 800ps, 2ns 100Hz
Quantas Q1 QLI Quantas-Q1-1064 Pulsed DPSS Lasers 0.100, 0.150, 0.350, 0.600 10000.0, 15000.0, 35000.0, 60000.0 7ns, 8ns 10Hz
Quantas-Q2-1064: High Energy, Compact, Nanosecond, DPSS Laser Quantas-Q2-1064 Pulsed DPSS Lasers 0.100, 0.150, 0.350, 0.600 10000.0, 15000.0, 35000.0, 60000.0 7ns, 8ns 10Hz
Quantas-Q2HE-1064: High energy, compact, nanosecond, DPSS laser Quantas-Q2HE-1064 Pulsed DPSS Lasers 1.0, 1.6, 2.0, 3.5, 4.0 40000.0, 70000.0, 80000.0, 100000.0 6ns 10Hz, 20Hz, 50Hz, 100Hz
R Series R1064 LD Module, Single Emitter, Volume Bragg Grating (VBG) Laser Diodes 0.120, 0.150, 0.300, 0.350, 0.500, 0.600, 0.800, 1.5 Single-Mode Lasers, Multimode Free Space, MM Fiber, PM Fiber Narrow
R1064.X Single Emitter, Volume Bragg Grating (VBG) Laser Diodes 0.050, 0.120, 0.300, 0.500 Single-Mode Lasers Free Space, PM Fiber Narrow
KA64HAMCA-10.00W: 1064nm Fiber Coupled Laser Diode RPKA64M Multi-Emitter 20.0 Multimode MM Fiber
RWLD 5.5mm Package Laser Diode RWLD-1064M Single Emitter 8.0, 10.0 Multimode Free Space
RWLP-1064M: 1064nm MultiMode Laser Diode RWLP-1064M Single Emitter 1.0, 8.0, 25.0 Multimode MM Fiber
RWLP-1064S: 1064nm Single Mode Laser Diode RWLP-1064S Single Emitter 0.005, 0.010, 0.015, 0.020, 0.030, 0.040, 0.050 Single-Mode Lasers SM Fiber, PM Fiber
RXXXXP-EC-AB-XXX-WD-DW RXXXXP-EC-AB-XXX-WD-DW Raman Probes 0.085, 0.100, 0.125
Bright Microlaser Microchip SB1 Laser SB1-1064 Pulsed DPSS Lasers, Microchip Lasers 0.008, 0.012, 0.040, 0.110, 0.150, 0.200, 0.225, 0.400 2.0, 15.0, 20.0, 30.0, 40.0, 60.0, 80.0 400ps, 1.3ns 100Hz, 200Hz, 1kHz, 5kHz, 10kHz, 15kHz, 55kHz, 100kHz
Sirius-532: Picosecond DPSS lasers Sirius IR Pulsed DPSS Lasers, Ultrafast Lasers 5.0 60.0 10ps Single shot to 1MHz
SOL-06: 1064nm compact nanosecond laser SOL-1064 Pulsed DPSS Lasers 4.0, 6.0, 10.0, 20.0, 30.0, 40.0 300.0, 450.0, 900.0, 1500.0, 2000.0 5ns - 35ns, 7ns - 35ns, 10ns - 40ns, 10ns - 50ns, 15ns - 60ns Single Shot to 100kHz
Vento-1064 Pulsed DPSS Lasers 16.0, 25.0, 40.0 600.0, 1000.0, 1500.0 500ps - 1.5ns 50kHz to 120kHz, 80kHz to 200kHz
Wedge-B-1064 Wedge-HB/XB 1064 Pulsed DPSS Lasers 4.0 2000.0, 4000.0 1.5ns Single shot to 1kHz, Single shot to 2kHz
Wedge-F-1064 Wedge-HF/XF 1064 Pulsed DPSS Lasers 1.5, 4.0 70.0, 180.0 400ps - 1.5ns, 400ps - 1.6ns, 700ps - 2.5ns 10kHz to 100kHz, 50kHz to 200kHz

Matchbox Series

R1Z4-Matchbox Laser

The Matchbox series offers excellent performance and reliability in the “World’s Smallest” ultra-compact, all-in-one, integrated laser head. They can operate on a 5V power supply while maintaining low noise operation. The monolithic design of the Matchbox Series laser includes thermally stabilized optics in a hermetically sealed housing, ensuring reliable and maintenance-free operation. This series is available in wavelengths from 405 nm thru 1064nm, with options for collimated beam or fiber-coupled output, and single-mode and multimode version.

Aero Series

Aero Laser by Bright SolutionsThe Aero Series is a high-energy DPSS laser that operates at less than 15 nanoseconds with multiple wavelength options including 266, 355, 532, and 1064nm. This series provides unparalleled precision and accuracy in even the most challenging environments. All models come enclosed in an extremely compact and ruggedized single unit with a conductively cooled heatsink with a water-cooled option. It comes with available options for beam expanding and collimating optics. This laser series is ideal for applications like LIBS, spectroscopy, and Atmospheric LIDAR.

Airtrac-MIL Series

AIRTRAC-LD

The AIRTRAC-MIL series is a ruggedized, high-shock, ultra-compact, actively q-switched, low-SWaP, DPSS laser, available with >90 mJ of pulse energy. Fully compliant NATO STANAG 3733 configurations for laser designation are available in a complete system weighing less than 1 lb. The athermal design of the AIRTRAC ensures high laser pulse energy, stable performance over the full temperature range with low beam divergence.

Alcor Series

Alcor

The Alcor series is the most advanced femtosecond fiber laser emitting at 920 nm or 1064 nm, designed explicitly for multiphoton microscopy, with the 920-1 & 920-2 providing the best performance on the market with ultrashort, clean pulses, all at a competitive price. Our lasers offer high pulse energy, short and clean pulses, and ultimate peak powers. With an ultra-compact, robust, and air-cooled design, our lasers are highly stable and reliable with low maintenance. Our XSight and FLeX fiber external modules allow for precise power control and gating and GDD precompensation. The Alcor series provides a complete and reliable solution for multi-photon microscopy, with seamless OEM integration.

Antares Series

Antares

The ANTARES is a series of high-energy picosecond lasers designed for ease-of-use and integration in biophotonics and nonlinear spectroscopy applications. With a narrow linewidth, high repetition rate up to 80 MHz, excellent beam quality, and average powers from 1W to 40W at 1030 nm or 1064 nm, ANTARES is ideal for high-speed nonlinear spectroscopy applications such as CARS and FRET microscopy. Additional options include fine-tuning PRF synchronization, ultra-narrow linewidth, second and third harmonic options, custom repetition rates, and more.

CEUV Series

R0Z2-Image-Compact-Efficient-UV-LaserThe CEUV series is a commercial line of compact and efficient DPSS laser sources, capable of operating over a wide range of pulsing conditions (duty-cycle and PRF), in a low SWaP package, with average power up to ≈5W @ 266nm, 10W @ 355nm or 532nm, 20W @ 1064nm. This series of DPSS lasers provides a combination of compact, efficient, and high-power performance in a rugged design suitable for harsh environments and airborne applications. The design has been tested in brassboard hardware and a prototype is being developed.

Diadem Series

DIADEM Series

The DIADEM series is a compact, versatile, air-cooled, high-energy, ultrafast femtosecond laser, operating at 1030 or 1064 nm for advanced micro-machining applications. Available with up to 40µJ of pulse energy, pulse widths down to ≈ 400 fs, an M² < 1.2, and single-shot up to 2MHz repetition rate, the DIADEM has many pulse control features such as adjustable pulse duration, selectable repetition rate from 40 MHz down to single-shot, or fine pulse energy tuning so that pulses can be emitted in various modes (on demand via external signal, burst of pulses with configurable pulse separation). A 1300 nm version is also available for deep brain imaging.

LaserBoxx Low Noise Series

The LaserBoxx Low Noise series of CW diode laser modules, with a variety of wavelengths from 375 to 785nm and output powers up to 350mW, offers highly customizable laser solutions for OEM and plug & play modules. With advanced features such as excellent beam quality, stability, and modulation capabilities, our lasers provide ultra-low noise and a wide range of options for SM, MM, and PM fiber coupling. Our dedicated control software, USB and RS232 interfaces, and external controller with power display make integration, operation, and remote diagnostics a breeze. Additionally, our rugged and compact design and wide variety of standard wavelengths ensure that our lasers can meet your specific needs.

LaserBoxx SLM Series

The LaserBoxx-SLM series are single longitudinal mode (SLM) CW diode laser modules available in green, yellow, red, and NIR wavelengths, delivering ultra-narrow linewidths, with excellent temperature stability and low noise current. Embedded firmware locks the laser on the same mode at each startup. This customizable, compact, self-contained laser module is available in turn-key or OEM versions and utilizes a proprietary alignment-free, monolithic resonator, and comes standard with a graphic user interface with remote diagnostics via USB, RS232, or direct I/O interface. With modulation capabilities and adjustable power options, the SLM Series is versatile and adaptable to a wide range of applications.

LDX Series

The LDX Series of made-in-the-US, high-power, multimode laser diodes provide wavelengths from 400nm – 1900nm, a wide range of output powers and package types, as well as completely customized solutions. We have been offering these high-quality laser diodes for over 25 years. The performance, reliability, and lifetimes are time tested, and if for some reason there is an issue, we will make it right.

neoMOS Series

neoMOS 700fsThe neoMOS ultrashort pulse laser series is a reliable and low maintenance system designed for 24/7 industrial use. Its ultra-compact laser head has the smallest footprint available, making it easy to integrate into different systems. The laser systems are highly flexible and can be customized to meet specific needs, providing a wide range of laser parameters and pulse durations. With available pulse durations between 700fs and 70ps, repetition rates from single-shot to 80MHz, up to 500µJ pulse energy, average output powers up to 100W, multi-megawatt peak powers, and perfect TEM00 beam quality, these lasers can tackle many applications and are ideal for processing demanding materials such as transparent glasses and plastics.

neoAMP Series

neoVAN - DPSS AmplifierThe neoAMP series includes the neoVAN and neoYb DPSS laser amplifiers, designed to boost the average power or pulse energy for a wide range of applications. The flexible system design ensures a high degree of scalability, and the ultra-compact modules are easy to integrate into existing processing or scientific systems. The neoVAN and neoYb amplifiers are highly reliable and offer proven long-term stability, enabling a range of applications that include high peak power, short pulse picosecond lasers for micromachining, or single-frequency radiation for gravitational wave detection.

Nps Series

Nps-1064-10

The NPS series of ultrafast lasers is the ultimate solution for OEM integrators and researchers working with nonlinear optics applications like OPO pumping and narrowband Raman spectroscopy. The NPS series boasts remarkable features such as up to 10W average output power, <7ps pulse width, and a 40MHz repetition rate. The transform-limited operation, with a spectral width of <0.3nm, and accurate central wavelengths make these lasers a suitable candidate for highly efficient amplification by Nd-doped DPSS amplifiers.

Onda Series

Onda 532nm: 532nm High Energy Laser

The Onda series is a DPSS nanosecond OEM laser platform designed for high-end applications requiring excellent beam quality and high peak power in materials such as metals, glass, plastics, and various delicate and hard materials. This compact and easy to use laser series is available in wavelengths of 266, 355, 532, and 1064nm, with an extended operating temperature range and superior performance to cost ratio. The Onda seriesinternal optical layout and accurate temperature management enable high output energies without compromising the lifetime of the THG and FHG stages.

Q-Spark

Quantas-Q-SPARK-266: High energy, compact, nanosecond, DPSS laser

The Q-SPARK series is an air-cooled, diode-pumped, Q-switched laser designed for researchers and application specialists working with ablation, LIDAR, remote sensing, and LIBS applications. The laser produces sub-nanosecond or nanosecond pulses with peak power up to 20 MW and pulse energies up to 10 mJ, making it ideal for a wide range of applications. With a short <1.5 ns pulse, compact air-cooled package, and innovative water-free laser crystal end-pumping technology, the Q-SPARK series delivers high-quality, low divergence, Gaussian-like laser beams.

Q1 Series

Quantas-Q1-211: High energy, compact, nanosecond, DPSS laser

The Q1 series is a compact, energy-efficient, diode pumped, air-cooled, Q-switched laser available at 1064 and 1053nm with up to 45 mJ of pulse energy and rep rates up to 50Hz. The high peak powers and low divergence of the Q1 series enable efficient harmonic conversion through the 5th harmonic (213 or 211nm). The innovative design results in a user-friendly, turnkey system that requires little maintenance, and the laser’s variable pulse repetition rate and built-in sync pulse generator provide flexibility for triggering user equipment.

Q2 Series

Quantas Q2 QLI

The Q2 series is a diode-pumped, fully air-cooled, Q-switched laser designed for a wide range of applications that require high peak power pulses. Its innovative water-free laser crystal end-pumping technology produces Gaussian-like, low divergence laser beams with high peak powers, allowing for efficient harmonics conversion through the 5th harmonic. This versatile platform can be configured in many ways, including up to 80mJ pulse energy at 10 Hz pulse repetition rate or up to 20mJ at 100 Hz. The laser can emit either 1053 nm or 1064 nm wavelength, and in the short cavity configuration, pulse duration can be reduced by 50% in comparison to standard configuration.

Q2HE Series

Quantas-Q2HE-211: High energy, compact, nanosecond, DPSS laser

The Q2HE series is a highenergy, q-switched, diode-pumped solid-state (DPSS) laser series, available in either 1053nm or 1064nm fundamental wavelengths, with optional 2nd, 3rd, 4th, or 5th harmonic generation. This air-cooled series of lasers is designed for a wide range of applications that require high peak power pulses. Due to a short laser cavity, excellent thermal properties of the crystal, and an innovative water-free crystal cooling technology, the Q2HE series can deliver up to 120mJ of pulse energy and/or up to 4W average output power. This advanced laser design results in a compact, user-friendly turnkey system that requires little maintenance.

R Series

R Series

The R series of wavelength stabilized singlemode and multimode laser diodes offer narrow linewidth output in wavelengths from 633nm thru 1064nm. This highly customizable series offers package options ranging from components as basic as a TO-56 or 14-pin BF packaged diodes, to OEM modules including electronics, to UL/CE and IEC certified turn-key systems. The R series is the perfect source for various markets, including chemical analysis, bio-medical, fiber laser, and scientific applications.

RPK Series

The RPK Series of multiple, single-emitter fiber-coupled diode lasers are available in wavelengths from 405nm thru 1550nm with up to 300W output power. Our specialized fiber-coupling techniques ensure high efficiency, stability, and superior beam quality, while rigorous inspections and burn-in procedures guarantee each product’s reliability, stability, and long lifetime. Highly customizable packages allow us to meet our customers’ specific needs, providing high-quality products at reasonable prices.

RWLD Series

The RWLD series offers competitively priced laser diodes with high beam quality and a wide variety of products to support multiple applications. Available in a wide range of wavelengths, power levels, and packages. The RWLD wavelength options span from 405nm to 1650nm, with output powers in the range of 10 mW to 300 mW, packaged in a TO-18 package with photodiode. We also offer customized options, such as a customized wavelength, output power, or a special package to meet your specific needs.

RWLP Series

R3Z0-WSLP-905-050m-M-PD: 905nm Multimode Fiber Coupled Laser Diode

The RWLP series offers an affordable and versatile solution for your laser application needs with single-mode and multimode options and wavelengths from 405nm thru the IR region. With customizable options, our team can work with you to solve any challenges you may face. Rigorously tested for long-term reliability, the RWLP series ensures consistent performance and high beam quality. Perfect for integration, this series supports multiple applications including biological and analytical instrumentation.

Microchip Series

Bright Microlaser Microchip SB1 Laser

The Microchip series is a line of ultra-compact, passively q-switched, single longitudinal mode (SLM), narrow linewidth, DPSS lasers that offer exceptional performance in a compact form factor. The lasers feature pulse durations ranging from 400 ps to 2 ns, energy levels up to 80 µJ, and repetition rates up to 100 kHz. Available in wavelengths from the UV to the NIR, this series is designed for OEM integrators and researchers working with LIDAR, 3D scanning, LIBS, night vision, and more. The lasers offer both nanosecond and picosecond options and are interchangeable with the same form factor and electrical and software interfaces across wavelengths, making them a flexible and versatile solution.

Sirius Series

Sirius-532: Picosecond DPSS lasers

The SIRIUS series is a very compact, high-energy hybrid ultrafast laser for advanced micro-machining applications and supercontinuum pumping, offering over 60µJ and > 5 W @ 1064 nm, with pulses below 10 ps from single shot to 1MHz and an M² of < 1.2. SIRIUS is a fully configurable laser offering various pulse generation modes: selectable pulse durations and repetition rates, burst, gating and fine energy control. This laser series is specifically designed to allow for ergonomic and user-friendly operation. Also available in green or UV wavelengths, SIRIUS is ideally suited for selective ablation, electronics, and photonic applications.

SOL Series

SOL-03-532: 532nm Nanosecond Laser

The SOL series is the most compact, air-cooled, Q-switched DPSS nanosecond laser available in the power range from 4W to 40W @ 1064nm. Available @ 1064nm, 532nm, and 355nm, the SOL laser series offers excellent beam quality and high peak power, capable of up to 10W and 650µJ at 532nm and 4W @ 355nm, making it the ideal source for the most demanding industrial and scientific applications. With a rugged, compact, lightweight, and easy to use single unit design, the SOL laser is easy to integrate into micro-machining and marking applications, providing superior operational flexibility and performance/cost ratio.

Vento Series

Vento-532-7: 532nm Picosecond DPSS Laser

The Vento series is a compact and ruggedized sub-nanosecond DPSS laser series designed for OEM integrators, application specialists, and researchers working with scientific and industrial applications such as precision LIDAR and materials processing. With pulse durations down to 500 ps and repetition rates up to 200 kHz, this laser series produces high average power of up to 25 W @ 532 nm and up to 40 W @ 1064 nm. The Vento series features beam expanding and collimating optics, low jitter option, extended operating temperature range, pulse energy modulation up to IP68 Package, circular polarization, remote control cbox and software interface, air and water-cooled options, and AC-DC power supply.

Wedge Series

Wedge-XF-1064: 1064nm Picosecond Laser

The Wedge series is a line of DPSS lasers designed specifically for OEM applications such as micro machining of hard and soft materials, specialty marking, glass and crystal engraving, LIDAR, LIBS, spectroscopy, and medical diagnostics. These diodepumped lasers, based on proprietary fast Q-switching technology, are compact, sealed, and monolithic which makes them insensitive to vibrations and harsh environments. With high peak powers and relatively low energy and heat generation, they allow efficient ablation and non-linear interaction with most materials. The compact and lightweight package is a great benefit in LIDAR and other aerospace applications, while short pulses provide extremely precise time-of-flight measurements.
