60mW Lasers

What are 60mW Lasers?

60mW lasers can be any laser that designates 60mW (0.06W) of output power, having either CW (continuous-wave) or pulsed output. CW Lasers are always defined in average output power. Pulsed Lasers with an output power defined in Watts or Milliwatts usually define the laser’s average power, not the peak power of the laser.

Our 60mW Laser Products

RPMC offers a selection of lasers emitting 60mW of average output power, including various types such as single emitter diode lasers, volume Bragg grating (VBG) laser diodes, vertical-cavity surface-emitting laser (VCSEL) diodes, LD modules, CW and pulsed DPSS lasers, and microchip lasers.

We provide multiple standard configuration options for our 60mW lasers. For example we have several versions of end-pumped, pulsed DPSS lasers, available in 10 different wavelengths from 211nm to 532nm, capable of tackling many different applications.

If you can not find the right laser to fit your needs among our standard options, please contact us at RPMC. We can usually provide options for customization to our products, and we can even supply you with a fully customized solution, tailored to your unique application requirements.

Filters Reset

Type

Wavelength Selection

Power Selection

Energy Selection

Pulse Width Selection

Mode

Output

Linewidth

Series

Picture Part Number Type Wavelength (nm) Output power (W) Mode Output Linewidth Pulse energy (uJ) Pulse width Rep rate
450L-3XA: 450nm Laser (HP MM Diode; MATCHBOX 2) 450L-1XA LD Module 450 0.035, 0.050, 0.060 Single-Mode Lasers Free Space, MM Fiber, SM Fiber, PM Fiber
505L-1XA LD Module 505 0.060 Single-Mode Lasers Free Space, MM Fiber, SM Fiber, PM Fiber
638L-1XA: 638nm Laser (Diode; MATCHBOX 2) 638L-1XA LD Module 638 0.060, 0.080, 0.100, 0.120, 0.170, 0.500, 0.600 Single-Mode Lasers Free Space, MM Fiber, SM Fiber, PM Fiber
638L-2XA: 638nm SLM Laser (VBG Diode; MATCHBOX 2) 638L-2XA LD Module 638 0.060, 0.080, 0.100 Single-Mode Lasers Free Space, MM Fiber, SM Fiber, PM Fiber Narrow
660L-1XA: 660nm Laser (Diode; MATCHBOX 2) 660L-1XA LD Module 660 0.060, 0.080, 0.090, 0.110 Single-Mode Lasers Free Space, MM Fiber, SM Fiber, PM Fiber
JenLas-D2-X-Series-Thin-Disk-DPSS-Laser-Green-532nm JenLas D2.X CW DPSS Lasers 532 0.060, 2.0, 3.0, 5.0, 8.0 Multimode Free Space, MM Fiber
LBX-488 LD Module 488 0.040, 0.050, 0.060, 0.100, 0.150, 0.200, 0.300 Single-Mode Lasers Free Space, MM Fiber, SM Fiber, PM Fiber
Q-Shift Series Quantas-Q-SHIFT-388 Pulsed DPSS Lasers 388 0.060, 0.096, 0.120 600.0, 1200.0, 2400.0, 3600.0, 4800.0, 6000.0 2ns - 5ns 10Hz, 20Hz, 33Hz, 50Hz, 100Hz
Q-Shift Series Quantas-Q-SHIFT-393 Pulsed DPSS Lasers 393 0.060, 0.096, 0.120 600.0, 1200.0, 2400.0, 3600.0, 4800.0, 6000.0 2ns - 5ns 10Hz, 20Hz, 33Hz, 50Hz, 100Hz
Quantas-Q1-263: High energy, compact, nanosecond, DPSS laser Quantas-Q1-263 Pulsed DPSS Lasers 263 0.015, 0.020, 0.030, 0.036, 0.060, 0.070, 0.075 300.0, 700.0, 1000.0, 1500.0, 1800.0, 3000.0, 7000.0 10ns Single Shot to 10Hz, Single Shot to 20Hz, Single Shot to 50Hz
Quantas-Q1-266: High energy, compact, nanosecond, DPSS laser Quantas-Q1-266 Pulsed DPSS Lasers 266 0.015, 0.020, 0.030, 0.036, 0.050, 0.060, 0.075 300.0, 700.0, 1000.0, 1500.0, 1800.0, 3000.0, 5000.0 10ns Single Shot to 10Hz, Single Shot to 20Hz, Single Shot to 50Hz
Quantas-Q1-351: High energy, compact, nanosecond, DPSS laser Quantas-Q1-351 Pulsed DPSS Lasers 355 0.030, 0.050, 0.060, 0.075, 0.100, 0.130, 0.150 600.0, 1500.0, 2500.0, 3000.0, 5000.0, 6000.0, 7500.0, 13000.0 10ns Single Shot to 10Hz, Single Shot to 20Hz, Single Shot to 50Hz
Quantas-Q1-355: High energy, compact, nanosecond, DPSS laser Quantas-Q1-355 Pulsed DPSS Lasers 355 0.030, 0.050, 0.060, 0.075, 0.100, 0.150 600.0, 1500.0, 2500.0, 3000.0, 5000.0, 6000.0, 7500.0, 10000.0 10ns Single Shot to 10Hz, Single Shot to 20Hz, Single Shot to 50Hz
Quantas-Q1-527: High energy, compact, nanosecond, DPSS laser Quantas-Q1-527 Pulsed DPSS Lasers 527 0.050, 0.060, 0.080, 0.100, 0.125, 0.150, 0.220, 0.250 1200.0, 2500.0, 4000.0, 5000.0, 7500.0, 10000.0, 12500.0, 22000.0 10ns Single Shot to 10Hz, Single Shot to 20Hz, Single Shot to 50Hz
Quantas-Q1-532: High energy, compact, nanosecond, DPSS laser Quantas-Q1-532 Pulsed DPSS Lasers 532 0.050, 0.060, 0.080, 0.100, 0.125, 0.150, 0.170, 0.250 1200.0, 2500.0, 4000.0, 5000.0, 7500.0, 10000.0, 12500.0, 17000.0 10ns Single Shot to 10Hz, Single Shot to 20Hz, Single Shot to 50Hz
Quantas-Q2-211: High energy, compact, nanosecond, DPSS laser Quantas-Q2-211 Pulsed DPSS Lasers 211 0.035, 0.060, 0.080, 0.120 20.0, 500.0, 1000.0, 1800.0, 2500.0, 3000.0, 5000.0 5ns, 6ns, 7ns, 8ns 10Hz, 20Hz, 33.3Hz, 50Hz
Quantas-Q2-213: High energy, compact, nanosecond, DPSS laser Quantas-Q2-213 Pulsed DPSS Lasers 213 0.060, 0.075, 0.080, 0.120, 0.150 20.0, 500.0, 1000.0, 1800.0, 2500.0, 3000.0, 5000.0 5ns, 6ns, 7ns, 8ns, 10ns 10Hz, 20Hz, 33.3Hz, 50Hz, 100Hz, 200Hz
R Series R0638 LD Module, Single Emitter, Volume Bragg Grating (VBG) Laser Diodes 638 0.030, 0.035, 0.050, 0.060, 0.085, 0.100, 0.125, 0.300, 0.350 Single-Mode Lasers, Multimode Free Space, MM Fiber, PM Fiber Narrow
R Series R0660 LD Module, Single Emitter, Volume Bragg Grating (VBG) Laser Diodes 660 0.030, 0.060, 0.250 Single-Mode Lasers, Multimode Free Space, MM Fiber, PM Fiber Narrow
RWLD 5.5mm Package Laser Diode RWLD-480S Single Emitter 480 0.060, 0.080 Single-Mode Lasers Free Space
RWLD 5.5mm Package Laser Diode RWLD-488S Single Emitter 488 0.060, 0.080, 0.100 Single-Mode Lasers Free Space
RWLD 5.5mm Package Laser Diode RWLD-495S Single Emitter 495 0.060, 0.080 Single-Mode Lasers Free Space
Bright Microlaser Microchip SB1 Laser SB1-946 Pulsed DPSS Lasers, Microchip Lasers 946 0.004, 0.060, 0.070, 0.105 7.0 2ns 100Hz, 5kHz, 10kHz
VD-0940I-004W-1C-2A0: 940nm VCSEL Diode VD-0940-CW VCSELs 940 0.008, 0.020, 0.060, 0.070, 0.140, 0.150, 0.160, 0.200, 0.250, 0.500, 2.0, 4.0 Single-Mode Lasers Free Space

Matchbox Series

R1Z4-Matchbox Laser

The Matchbox series offers excellent performance and reliability in an ultra-compact “all-in-one” integrated laser head.  They come standard with an integrated internal voltage up-conversion that allows using a 5V power supply while maintaining low noise operation. The monolithic design of the Matchbox Series laser includes thermally stabilized optics in a hermetically sealed housing, ensuring reliable and maintenance-free operation.  All the Matchbox series modules include a 12-month warranty and are RoHS compliant.  All of these features make them the ideal laser source for integration into commercial flow cytometers.

JenLas D2

The JenLas D2 series of CW disk lasers with a wavelength of 532nm are available with up to 8W output power. These Nd:YVO4 or Yb:KYW solid state lasers are ideal for industrial micro material processing and medical treatments

LaserBoxx Low Noise Series

The LaserBoxx low noise Series is a CW diode laser module in a variety of diode wavelengths from 375 to 785nm, with output powers up to 350mW. This compact, self-contained laser module is available in turn-key or OEM versions and utilizes a proprietary alignment-free, monolithic resonator, and comes standard with a graphic user interface with remote diagnostics via USB, RS232, or direct I/O interface.

Q-SHIFT Series

Q-Shift SeriesThe Quantas-Q-SHIFT series is a family of Q-switched DPSS lasers featuring a built‑in nonlinear wavelength conversion stage, allowing the production of wavelengths that are not accessible with conventional solid-state laser sources, including 1163, 1177, 1300, 1317, 1551 and 1571nm. An optional harmonics generator is also available for for the Q-SHIFT, allowing generation of up to the 4th harmonic for each fundamental wavelength.

Q1 Series

Quantas-Q1-211: High energy, compact, nanosecond, DPSS laser

The Q1 series is a compact, energy-efficient, diode pumped, air-cooled, Q-switched laser available at 1064 and 1053nm with up to 45 mJ of pulse energy and rep rates up to 50Hz. The high peak powers and low divergence of the Q1 series enable efficient harmonic conversion through the 5th harmonic (213 or 211nm). The innovative laser design has resulted in a user-friendly, turnkey system that requires little maintenance.

Q2 Series

Quantas Q2 QLI

The Q2 series is a versatile, diode pumped, air-cooled, Q-switched laser capable of achieving up to 80mJ of pulse energy with an operational rep rate up to 100Hz. Available at the fundamental wavelengths of 1064 and 1053nm, the innovative water-free laser crystal end-pumping technology produces Gaussian-like, low divergence laser beams with high peak powers, enabling efficient harmonics conversion through the 5th harmonic.

R Series

R Series

The R series of wavelength stabilized single mode and multimode laser diodes offer narrow wavelength spectrum in wavelengths from 633nm thru 1064nm. Package options range from components as basic as a TO-56 or 14-pin BF packaged diodes, to OEM modules including electronics, to UL/CE and IEC certified turn-key systems.

RWLD Series

The RWLD series of laser diodes are available in a wide range of wavelengths, power levels, and packages. The RWLD wavelength options span from 405nm to 1650nm, with output powers in the range of 10 mW to 300 mW, packaged in a TO-18 package with photodiode. Custom wavelengths, powers, and packages upon request.

Microchip Series

Bright Microlaser Microchip SB1 Laser

The Microchip Series, from BrightMicroLaser, are ultra-compact, passively q-switched, single longitudinal mode (SLM), narrow linewidth, DPSS lasers that feature pulse durations from 400 ps to 2 ns, energy levels up to 80 uJ and repetition rates up to 100 kHz. In addition to the fundamental 1064 nm wavelength and its harmonics (532, 355 and 266 nm), we also deliver units emitting at 946 and 473 nm.

VD Series

VD-0940I-004W-1C-2A0: 940nm VCSEL Diode

The VD Series of Vertical Cavity, Surface Emitting Laser (VCSEL) emitters, and arrays are available in a wide range of output powers in wavelengths of 650 nm, 808 nm, 850 nm, and 940 nm.  Standard options include VCSEL, VCSEL w/ Diffusor, VCSEL & PD w/ Diffusor, and pulsed VCSELs.  These low-cost lasers are ideal for a wide range of consumer products.
