What is a pulsed laser?

Pulsed lasers have a gain medium that is typically optically pumped using either a flashlamp (arc lamp) or by laser diodes (DPSS). Utilizing pulse generation techniques like mode-locking and active and passive Q-switching, these lasers produce high peak power or high energy pulses with a lower duty cycle by storing energy and releasing then it in pulses. This method of repeated energy storage and release is unlike CW Lasers and Laser Diodes, which emit energy continuously. Pulsed Lasers are available in wide range of pulse widths from femtosecond through millisecond. The repetition rates range from single shot to Mhz.

Image Pulsed DPSS Lasers Electro-Optic Active Q-Switch Example DiagramActive Q-Switched Lasers allow the precise control of both the pulse width and repetition rate of the laser using an on / off system of blocking or emitting photons.  Active Q-switches are typically electro-optic, acousto-optic, or magneto-optic modulators, although other methods may be used, such as a mechanical shutter, optical chopper wheel, or spinning mirror / prism.

    • Strengths – Control over pulses, typically higher pulse energies
    • Weaknesses – Higher cost, System complexity, much larger than passive

Image-Pulsed-DPSS-Lasers-Saturable-Absorber-Passive-Q-Switch-Example-Diagram-1

Passive Q-Switched Lasers contain a Saturable Absorber that, when continuously pumped, produces a regular pulse train. Passive Q-Switch lasers cannot precisely control the pulse externally. Passive Q-Switches can be based on a special dye, a passive semiconductor, or a crystal material (typically Cr:YAG).

    • Strengths – Lower cost, System simplicity, Compact size
    • Weaknesses – No control over pulses, typically lower pulse energies

Mode-Locked Lasers (Ultrafast Lasers) produce ultrashort, typically sub-picosecond pulses, at high repetition rates (up to 80 MHz for our current product offerings) by mode locking a large number of phase-locked longitudinal modes from a broadband laser or from a material with a large gain bandwidth.

Our Pulsed Laser Products

RPMC Lasers offers a wide selection of Pulsed Laser technologies (Types). For example, these types include Diode-Pumped Solid-State (DPSS) Lasers, Flash-lamp Lasers, Ultrafast LasersFiber Lasers, Microlasers/Microchip Lasers, Tunable Lasers, MIL-Spec Lasers, Micromachining Lasers, and Custom Lasers.

Utilizing pulse generation techniques like mode-locking and active and passive Q-switching, these lasers produce high peak power or high energy pulses with a lower duty cycle. These lasers provide Nanosecond (ns), Picosecond (ps) and Femtosecond (fs) laser pulse widths.

Our pulsed products are available in many wavelengths in the UV, Violet, Blue, Green, Yellow, Red, NIR, SWIR, and MWIR regimes. Furthermore, our lasers provide average output powers from a few mW to 100W and pulse energies from nanojoules to 100’s of millijoules. Finally, these options provide pulse repetition rates from single-shot up to 80MHz.



Filters Reset

Type

Wavelength Selection

Power Selection

Energy Selection

Pulse Width Selection

Rep Rate Selection

Series

Picture Part Number Type Wavelength (nm) Output power (W) Pulse energy (uJ) Pulse width Rep rate Q-switch type
cpfl 1.5a 1.5at 1.5t cpfl2 hfl 1.5um Pulsed Fiber Lasers Pulsed Fiber Lasers 1530-1564 0.150, 1.0, 4.0 5.0, 25.0, 80.0 400ps, 50ns 5kHz, 1MHz, 2MHz Active
Pulsed Fiber Laser 1um Pulsed Fiber Lasers Pulsed Fiber Lasers 1030-1100 5.0 150.0 400ps, 50ns 10kHz, 100kHz, 1MHz Active
Aero-1064 Pulsed DPSS Lasers 1064 5.0, 10.0 50000.0, 100000.0, 200000.0 20ns Single Shot to 50Hz, Single Shot to 100Hz Active
Aero-266 Pulsed DPSS Lasers 266 0.600 6000.0, 12000.0 20ns Single Shot to 50Hz, Single Shot to 100Hz Active
Aero-355 Pulsed DPSS Lasers 355, 355/532/1064 1.0 10000.0, 20000.0 20ns Single Shot to 50Hz, Single Shot to 100Hz Active
Aero-532 Pulsed DPSS Lasers 532, 532/1064 2.0, 6.0 20000.0, 40000.0 20ns Single Shot to 50Hz, Single Shot to 100Hz Active
AIRTRAC-LD AIRTRAC-LD Pulsed DPSS Lasers, Mil-Spec Lasers 1064 1.0 50000.0 10ns - 25ns 7-21Hz Active
ALCOR 5W: 1064nm Ultra-Compact Femtosecond Laser ALCOR 10XX Pulsed DPSS Lasers, Pulsed Fiber Lasers, Ultrafast Lasers 1040, 1064 2.0, 5.0 0.025, 0.062 100fs, 110fs 80MHz (Optional: 40MHz) Active
ALCOR 5W: 1064nm Ultra-Compact Femtosecond Laser ALCOR 520 Pulsed DPSS Lasers, Pulsed Fiber Lasers, Ultrafast Lasers 520 0.800, 2.0 0.025 180fs 80MHz (Optional: 40MHz) Active
ALCOR 5W: 1064nm Ultra-Compact Femtosecond Laser ALCOR 780 Pulsed DPSS Lasers, Pulsed Fiber Lasers, Ultrafast Lasers 780 0.800 0.010 150fs 80MHz Active
ALCOR 5W: 1064nm Ultra-Compact Femtosecond Laser ALCOR 920 Pulsed DPSS Lasers, Pulsed Fiber Lasers, Ultrafast Lasers 920 1.5, 2.5, 4.0 0.0187, 0.0312, 0.050 100fs, 110fs, 130fs 80MHz Active
ALCOR 5W: 1064nm Ultra-Compact Femtosecond Laser ALCOR Dual Pulsed DPSS Lasers, Pulsed Fiber Lasers, Ultrafast Lasers 920/1064 1.0, 2.0 0.0125, 0.025 100fs, 110fs, 130fs 80MHz Active
Altair: Femtosecond Laser Altair Pulsed DPSS Lasers, Pulsed Fiber Lasers, Ultrafast Lasers 1040 10.0, 20.0 0.125, 0.250, 1.0 150fs, 250fs 30MHz, 80MHz, Single shot to 40MHz Active
Antares Antares Pulsed DPSS Lasers, Pulsed Fiber Lasers, Ultrafast Lasers 1030, 1064 10.0, 20.0, 30.0 0.125, 0.250, 0.375, 0.500 10ps 80MHz Active
R0Z2-Image-Compact-Efficient-UV-Laser CEUV Series Pulsed DPSS Lasers 266, 355, 532, 1064 5.0, 10.0, 20.0 500.0, 1000.0, 2000.0 3ns 10kHz to 1MHz Active
DIADEM Series Diadem 1300 Pulsed DPSS Lasers, Ultrafast Lasers 1300 2.0 1.0 150fs Single shot to 2MHz Active
DIADEM Series Diadem IR Pulsed DPSS Lasers, Ultrafast Lasers 1030, 1064 10.0, 20.0, 30.0 10.0, 20.0, 30.0, 40.0 400fs, 10ps Single shot to 2MHz Active
Fiber Lasers Jenlas Fiber ns 25-105 Pulsed DPSS Lasers, Pulsed Fiber Lasers 1085 20.0, 30.0, 55.0, 100.0 700.0, 1000.0, 1100.0 125ns 30kHz to 80kHz, 50kHz to 100kHz, 100kHz to 200kHz Active
MicroMake: Micromachining Laser System MicroMake 532 Micromachining System 532 35.0 0.8kHz, 1kHz, 10kHz to 100kHz
neoMOS neoMOS Pulsed DPSS Lasers 1064 5.0, 15.0, 50.0, 75.0, 100.0 250.0, 400.0, 500.0 600fs, 700fs, 900fs, 10ps, 40ps, 70ps, 100ps Single shot to 80MHz
NPS-1064 Pulsed DPSS Lasers, Ultrafast Lasers 1064 0.050, 5.0, 10.0 0.125, 0.250 7ps 40MHz Passive
NPS-355 Pulsed DPSS Lasers, Ultrafast Lasers 355 1.0 0.025 7ps 40MHz Passive
NPS-532 Pulsed DPSS Lasers, Ultrafast Lasers 532 1.0, 5.0 0.025, 0.125 7ps 40MHz Passive
Onda 1064nm Onda 1064nm Pulsed DPSS Lasers 1064 15.0 800.0 2ns - 12ns Single Shot to 100kHz Active
Onda 266nm Onda 266nm Pulsed DPSS Lasers 266 0.800 80.0 2ns - 6ns Single shot to 1kHz, Single shot to 50kHz Active
Onda 355nm Onda 355nm Pulsed DPSS Lasers 355 0.300 150.0 3ns Single shot to 2kHz Active
Onda 532nm: 532nm High Energy Laser Onda 532nm Pulsed DPSS Lasers 532 5.0, 10.0 400.0, 800.0 2ns - 14ns Single Shot to 100kHz Active
One-1030-100: 1030nm Miniature Q-Switched Laser One-1030 Pulsed DPSS Lasers 1030 1.0, 3.0 100.0 5ns - 20ns 30kHz, Single shot to 10kHz Passive
Q-TUNE tunable DPSS laser Q-TUNE-IR Pulsed DPSS Lasers, Tunable Lasers Tunable 0.020, 0.065 2000.0, 6500.0 3ns - 4ns 10Hz, 20Hz Active
Q-TUNE tunable DPSS laser Q-TUNE Pulsed DPSS Lasers, Tunable Lasers Tunable 0.210 8000.0 5ns 10Hz, 33Hz, 100Hz Active
Q-Shift Series Quantas-Q-SHIFT-1163 Pulsed DPSS Lasers 1163 0.500, 0.800, 1.0 4000.0, 8000.0, 16000.0, 24000.0, 32000.0, 40000.0 2ns - 5ns 10Hz, 20Hz, 33Hz, 50Hz, 100Hz Active
Q-Shift Series Quantas-Q-SHIFT-1177 Pulsed DPSS Lasers 1177 0.500, 0.800, 1.0 4000.0, 8000.0, 16000.0, 24000.0, 32000.0, 40000.0 2ns - 5ns 10Hz, 20Hz, 33Hz, 50Hz, 100Hz Active
Q-Shift Series Quantas-Q-SHIFT-1300 Pulsed DPSS Lasers 1300 0.300, 0.480, 0.600 2000.0, 4000.0, 8000.0, 12000.0, 16000.0, 20000.0 2ns - 5ns 10Hz, 20Hz, 33Hz, 50Hz, 100Hz Active
Q-Shift Series Quantas-Q-SHIFT-1317 Pulsed DPSS Lasers 1317 0.300, 0.480, 0.600 2000.0, 4000.0, 8000.0, 12000.0, 16000.0, 20000.0 2ns - 5ns 10Hz, 20Hz, 33Hz, 50Hz, 100Hz Active
Q-Shift Series Quantas-Q-SHIFT-1551 Pulsed DPSS Lasers 1551 0.400, 0.640, 0.800 3000.0, 6000.0, 12000.0, 20000.0, 24000.0, 30000.0 2ns - 5ns 10Hz, 20Hz, 33Hz, 50Hz, 100Hz Active
Q-Shift Series Quantas-Q-SHIFT-1571 Pulsed DPSS Lasers 1571 0.400, 0.640, 0.800 3000.0, 6000.0, 12000.0, 20000.0, 24000.0, 30000.0 2ns - 5ns 10Hz, 20Hz, 33Hz, 50Hz, 100Hz Active
Q-Shift Series Quantas-Q-SHIFT-291 Pulsed DPSS Lasers 291 0.075, 0.120, 0.150 250.0, 500.0, 1000.0, 1500.0, 2000.0, 2500.0 2ns - 5ns 10Hz, 20Hz, 33Hz, 50Hz, 100Hz Active
Q-Shift Series Quantas-Q-SHIFT-294 Pulsed DPSS Lasers 294 0.075, 0.120, 0.150 250.0, 500.0, 1000.0, 1500.0, 2000.0, 2500.0 2ns - 5ns 10Hz, 20Hz, 33Hz, 50Hz, 100Hz Active
Q-Shift Series Quantas-Q-SHIFT-325 Pulsed DPSS Lasers 325 0.045, 0.072, 0.090 120.0, 250.0, 500.0, 750.0, 1000.0, 1300.0 2ns - 5ns 10Hz, 20Hz, 33Hz, 50Hz, 100Hz Active
Q-Shift Series Quantas-Q-SHIFT-329 Pulsed DPSS Lasers 329 0.045, 0.072, 0.090 120.0, 250.0, 500.0, 750.0, 1000.0, 1300.0 2ns - 5ns 10Hz, 20Hz, 33Hz, 50Hz, 100Hz Active
Q-Shift Series Quantas-Q-SHIFT-388 Pulsed DPSS Lasers 388 0.125, 0.200, 0.250 600.0, 1200.0, 2400.0, 3600.0, 4800.0, 6000.0 2ns - 5ns 10Hz, 20Hz, 33Hz, 50Hz, 100Hz Active
Q-Shift Series Quantas-Q-SHIFT-388 Pulsed DPSS Lasers 388 0.060, 0.096, 0.120 180.0, 360.0, 750.0, 1250.0, 1500.0, 1800.0 2ns - 5ns 10Hz, 20Hz, 33Hz, 50Hz, 100Hz Active
Q-Shift Series Quantas-Q-SHIFT-392 Pulsed DPSS Lasers 392 0.125, 0.200, 0.250 600.0, 1200.0, 2400.0, 3600.0, 4800.0, 6000.0 2ns - 5ns 10Hz, 20Hz, 33Hz, 50Hz, 100Hz Active
Q-Shift Series Quantas-Q-SHIFT-393 Pulsed DPSS Lasers 393 0.060, 0.096, 0.120 180.0, 360.0, 750.0, 1250.0, 1500.0, 1800.0 2ns - 5ns 10Hz, 20Hz, 33Hz, 50Hz, 100Hz Active
Q-Shift Series Quantas-Q-SHIFT-433 Pulsed DPSS Lasers 433 0.075, 0.120, 0.150 300.0, 600.0, 1200.0, 1800.0, 2400.0, 3000.0 2ns - 5ns 10Hz, 20Hz, 33Hz, 50Hz, 100Hz Active
Q-Shift Series Quantas-Q-SHIFT-439 Pulsed DPSS Lasers 439 0.075, 0.120, 0.150 300.0, 600.0, 1200.0, 1800.0, 2400.0, 3000.0 2ns - 5ns 10Hz, 20Hz, 33Hz, 50Hz, 100Hz Active
Q-Shift Series Quantas-Q-SHIFT-517 Pulsed DPSS Lasers 517 0.100, 0.160, 0.200 450.0, 900.0, 1800.0, 3000.0, 3600.0, 4500.0 2ns - 5ns 10Hz, 20Hz, 33Hz, 50Hz, 100Hz Active
Q-Shift Series Quantas-Q-SHIFT-524 Pulsed DPSS Lasers 524 0.100, 0.160, 0.200 450.0, 900.0, 1800.0, 3000.0, 3600.0, 4500.0 2ns - 5ns 10Hz, 20Hz, 33Hz, 50Hz, 100Hz Active
Q-Shift Series Quantas-Q-SHIFT-581.5 Pulsed DPSS Lasers 581.5 0.250, 0.400, 0.495, 0.500 1000.0, 2000.0, 4000.0, 6000.0, 8000.0, 10000.0 2ns - 5ns 10Hz, 20Hz, 33Hz, 50Hz, 100Hz Active
Q-Shift Series Quantas-Q-SHIFT-588.5 Pulsed DPSS Lasers 588.5 0.250, 0.400, 0.495, 0.500 1000.0, 2000.0, 4000.0, 6000.0, 8000.0, 10000.0 2ns - 5ns 10Hz, 20Hz, 33Hz, 50Hz, 100Hz Active
Q-Shift Series Quantas-Q-SHIFT-650 Pulsed DPSS Lasers 650 0.150, 0.240, 0.300 500.0, 1000.0, 2000.0, 3000.0, 4000.0, 5000.0 2ns - 5ns 10Hz, 20Hz, 33Hz, 50Hz, 100Hz Active
Q-Shift Series Quantas-Q-SHIFT-658.5 Pulsed DPSS Lasers 658.5 0.150, 0.240, 0.300 500.0, 1000.0, 2000.0, 3000.0, 4000.0, 5000.0 2ns - 5ns 10Hz, 20Hz, 33Hz, 50Hz, 100Hz Active
Q-Shift Series Quantas-Q-SHIFT-775.5 Pulsed DPSS Lasers 775.5 0.200, 0.320, 0.400 750.0, 1500.0, 3000.0, 5000.0, 6000.0, 7500.0 2ns - 5ns 10Hz, 20Hz, 33Hz, 50Hz, 100Hz Active
Q-Shift Series Quantas-Q-SHIFT-785.5 Pulsed DPSS Lasers 785.5 0.200, 0.320, 0.400 750.0, 1500.0, 3000.0, 5000.0, 6000.0, 7500.0 2ns - 5ns 10Hz, 20Hz, 33Hz, 50Hz, 100Hz Active
Q-Shift Series Quantas-Q-SHIFT-WXXXX Pulsed DPSS Lasers Multiple Wavelength Options Varies Varies 2ns - 5ns 100Hz Active
Nanosecond DPSS laser Quantas-Q-SPARK-1064 Pulsed DPSS Lasers 1064 0.010 10000.0 800ps, 2ns 100Hz Active
Quantas-Q-SPARK-266: High energy, compact, nanosecond, DPSS laser Quantas-Q-SPARK-266 Pulsed DPSS Lasers 266 0.010 1500.0 2ns 20Hz Active
Quantas-Q-SPARK-355: High energy, compact, nanosecond, DPSS laser Quantas-Q-SPARK-355 Pulsed DPSS Lasers 355 0.010 2500.0 2ns 20Hz Active
Quantas-Q-SPARK-532: High energy, compact, nanosecond, DPSS laser Quantas-Q-SPARK-532 Pulsed DPSS Lasers 532 0.010 2500.0 2ns 20Hz Active
Quantas-Q1-1053: High energy, compact, nanosecond, DPSS laser Quantas-Q1-1053 Pulsed DPSS Lasers 1053 0.100, 0.200, 0.350 10000.0, 20000.0, 35000.0 7ns, 8ns 10Hz Active
Quantas Q1 QLI Quantas-Q1-1064 Pulsed DPSS Lasers 1064 0.100, 0.150, 0.350, 0.600 10000.0, 15000.0, 35000.0, 60000.0 7ns, 8ns 10Hz Active
Quantas-Q1-211: High energy, compact, nanosecond, DPSS laser Quantas-Q1-211 Pulsed DPSS Lasers 211 0.005, 0.010, 0.020, 0.025 500.0, 1000.0, 2000.0, 2500.0 7ns, 8ns Single Shot to 10Hz Active
Quantas-Q1-213: High energy, compact, nanosecond, DPSS laser Quantas-Q1-213 Pulsed DPSS Lasers 213 0.005, 0.010, 0.020, 0.025 500.0, 1000.0, 2000.0, 2500.0 7ns, 8ns 10Hz Active
Quantas-Q1-263: High energy, compact, nanosecond, DPSS laser Quantas-Q1-263 Pulsed DPSS Lasers 263 0.015, 0.030, 0.050, 0.070 1500.0, 3000.0, 5000.0, 7000.0 7ns, 8ns Single Shot to 10Hz Active
Quantas-Q1-266: High energy, compact, nanosecond, DPSS laser Quantas-Q1-266 Pulsed DPSS Lasers 266 0.015, 0.030, 0.050, 0.070 1500.0, 3000.0, 5000.0, 7000.0 7ns, 8ns Single Shot to 10Hz Active
Quantas-Q1-351: High energy, compact, nanosecond, DPSS laser Quantas-Q1-351 Pulsed DPSS Lasers 355 0.030, 0.060, 0.100, 0.130 3000.0, 6000.0, 10000.0, 13000.0 7ns, 8ns Single Shot to 10Hz Active
Quantas-Q1-355: High energy, compact, nanosecond, DPSS laser Quantas-Q1-355 Pulsed DPSS Lasers 355 0.030, 0.060, 0.100, 0.130 3000.0, 6000.0, 10000.0, 13000.0 7ns, 8ns 10Hz Active
Quantas-Q1-527: High energy, compact, nanosecond, DPSS laser Quantas-Q1-527 Pulsed DPSS Lasers 527 0.050, 0.100, 0.170, 0.220 5000.0, 10000.0, 17000.0, 22000.0 7ns, 8ns 10Hz Active
Quantas-Q1-532: High energy, compact, nanosecond, DPSS laser Quantas-Q1-532 Pulsed DPSS Lasers 532 0.050, 0.110, 0.170, 0.220 5000.0, 10000.0, 17000.0, 22000.0 7ns, 8ns 10Hz Active
Quantas-Q2-1053: High energy, compact, nanosecond, DPSS laser Quantas-Q2-1053 Pulsed DPSS Lasers 1053 0.100, 0.150, 0.350, 0.600, 0.800 10000.0, 15000.0, 35000.0, 60000.0, 80000.0 5ns, 7ns, 8ns 10Hz Active
Quantas-Q2-1064: High Energy, Compact, Nanosecond, DPSS Laser Quantas-Q2-1064 Pulsed DPSS Lasers 1064 0.100, 0.150, 0.350, 0.600 10000.0, 15000.0, 35000.0, 60000.0 7ns, 8ns 10Hz Active
Quantas-Q2-211: High energy, compact, nanosecond, DPSS laser Quantas-Q2-211 Pulsed DPSS Lasers 211 0.004, 0.010, 0.020, 0.040, 0.050 400.0, 1000.0, 2000.0, 4000.0, 5000.0 5ns, 7ns, 8ns 10Hz Active
Quantas-Q2-213: High energy, compact, nanosecond, DPSS laser Quantas-Q2-213 Pulsed DPSS Lasers 213 0.004, 0.010, 0.020, 0.040, 0.050 400.0, 1000.0, 2000.0, 4000.0, 5000.0 5ns, 7ns, 8ns 10Hz Active
Quantas-Q2-263: High energy, compact, nanosecond, DPSS laser Quantas-Q2-263 Pulsed DPSS Lasers 263 0.012, 0.025, 0.050, 0.100, 0.120 1200.0, 2500.0, 5000.0, 10000.0, 12000.0 5ns, 7ns, 8ns 10Hz, 20Hz, 33.3Hz, 50Hz Active
Quantas-Q2-266: High energy, compact, nanosecond, DPSS laser Quantas-Q2-266 Pulsed DPSS Lasers 266 0.012, 0.025, 0.050, 0.100, 0.120 1200.0, 2500.0, 5000.0, 10000.0, 12000.0 5ns, 7ns, 8ns 20Hz, 33.3Hz, 50Hz, 100Hz, 200Hz Active
Quantas-Q2-351: High energy, compact, nanosecond, DPSS laser Quantas-Q2-351 Pulsed DPSS Lasers 351 0.024, 0.045, 0.090, 0.180, 0.240 2400.0, 4500.0, 9000.0, 18000.0, 24000.0 5ns, 7ns, 8ns 10Hz, 20Hz, 33.3Hz, 50Hz Active
Quantas-Q2-355: High energy, compact, nanosecond, DPSS laser Quantas-Q2-355 Pulsed DPSS Lasers 355 0.024, 0.045, 0.090, 0.180, 0.240 2400.0, 4500.0, 9000.0, 18000.0, 24000.0 5ns, 7ns, 8ns 10Hz Active
Quantas-Q2-527: High energy, compact, nanosecond, DPSS laser Quantas-Q2-527 Pulsed DPSS Lasers 527 0.040, 0.070, 0.150, 0.300, 0.400 4000.0, 7000.0, 15000.0, 30000.0, 40000.0 5ns, 7ns, 8ns 10Hz, 20Hz, 33.3Hz, 50Hz Active
Quantas Q2 QLI Quantas-Q2-532 Pulsed DPSS Lasers 532 0.040, 0.070, 0.150, 0.300, 0.400 4000.0, 7000.0, 15000.0, 30000.0, 40000.0 5ns, 7ns, 8ns 10Hz, 20Hz, 33.3Hz, 50Hz, 100Hz, 200Hz Active
Quantas-Q2HE-1053: High energy, compact, nanosecond, DPSS laser Quantas-Q2HE-1053 Pulsed DPSS Lasers 1053 1.2, 2.0 40000.0, 100000.0, 120000.0 6ns 10Hz, 20Hz, 50Hz Active
Quantas-Q2HE-1064: High energy, compact, nanosecond, DPSS laser Quantas-Q2HE-1064 Pulsed DPSS Lasers 1064 1.0, 1.6, 2.0, 3.5, 4.0 40000.0, 70000.0, 80000.0, 100000.0 6ns 10Hz, 20Hz, 50Hz, 100Hz Active
Quantas-Q2HE: High energy, compact, nanosecond, DPSS laser Quantas-Q2HE-211 Pulsed DPSS Lasers 211 0.050, 0.075, 0.080 1500.0, 4000.0, 5000.0 6ns 10Hz, 20Hz, 50Hz Active
Quantas-Q2HE-213: High energy, compact, nanosecond, DPSS laser Quantas-Q2HE-213 Pulsed DPSS Lasers 213 0.040, 0.070, 0.075, 0.150 1500.0, 3000.0, 3500.0, 4000.0 6ns 10Hz, 20Hz, 50Hz, 100Hz Active
Quantas-Q2HE-263: High energy, compact, nanosecond, DPSS laser Quantas-Q2HE-263 Pulsed DPSS Lasers 263 0.180, 0.250, 0.300 5000.0, 15000.0, 18000.0 6ns 10Hz, 20Hz, 50Hz Active
Quantas-Q2HE-266: High energy, compact, nanosecond, DPSS laser Quantas-Q2HE-266 Pulsed DPSS Lasers 266 0.600 5000.0, 10000.0 7ns 20Hz, 50Hz, 100Hz Active
Quantas-Q2HE-351: High energy, compact, nanosecond, DPSS laser Quantas-Q2HE-351 Pulsed DPSS Lasers 351 0.350, 0.600 12000.0, 30000.0, 35000.0 6ns 10Hz, 20Hz, 50Hz Active
Quantas-Q2HE-355: High energy, compact, nanosecond, DPSS laser Quantas-Q2HE-355 Pulsed DPSS Lasers 355 0.300, 0.500, 0.600, 1.0, 1.2 12000.0, 20000.0, 25000.0, 30000.0 6ns 10Hz, 20Hz, 50Hz, 100Hz Active
Quantas-Q2HE-527: High energy, compact, nanosecond, DPSS laser Quantas-Q2HE-527 Pulsed DPSS Lasers 527 0.600, 1.0 20000.0, 50000.0, 60000.0 6ns 10Hz, 20Hz, 50Hz Active
Quantas-Q2HE-532: High energy, compact, nanosecond, DPSS laser Quantas-Q2HE-532 Pulsed DPSS Lasers 532 0.500, 0.800, 1.0, 1.75, 2.0 20000.0, 35000.0, 40000.0, 50000.0 6ns 10Hz, 20Hz, 50Hz, 100Hz Active
Quantas-Q2HE: High energy, compact, nanosecond, DPSS laser Quantas-Q2HE-XXX-XXXX Pulsed DPSS Lasers Multiple Wavelength Options Varies Varies Varies 100Hz Active
Bright Microlaser Microchip SB1 Laser SB1-1064 Pulsed DPSS Lasers, Microchip Lasers 1064 0.008, 0.012, 0.040, 0.110, 0.150, 0.200, 0.225, 0.400 2.0, 15.0, 20.0, 30.0, 40.0, 60.0, 80.0 400ps, 1.3ns 100Hz, 200Hz, 1kHz, 5kHz, 10kHz, 15kHz, 55kHz, 100kHz Passive
Bright Microlaser Microchip SB1 Laser SB1-236.5 Pulsed DPSS Lasers, Microchip Lasers 236.5 0.001 0.200, 2.0 1.3ns 500Hz, 5kHz Passive
Bright Microlaser Microchip SB1 Laser SB1-266 Pulsed DPSS Lasers, Microchip Lasers 266 0.002, 0.005 0.500, 1.0, 2.0 1.3ns 1kHz, 5kHz, 10kHz Passive
Bright Microlaser Microchip SB1 Laser SB1-355 Pulsed DPSS Lasers, Microchip Lasers 355 0.010 1.0 1.3ns 10kHz Passive
Bright Microlaser Microchip SB1 Laser SB1-473 Pulsed DPSS Lasers, Microchip Lasers 473 0.0009, 0.010, 0.015 1.0, 3.0, 9.0 2ns 100Hz, 5kHz, 10kHz Passive
Bright Microlaser Microchip SB1 Laser SB1-532 Pulsed DPSS Lasers, Microchip Lasers 532 0.004, 0.006, 0.010, 0.017, 0.020, 0.030, 0.040, 0.075, 0.100 0.300, 7.0, 10.0, 15.0, 20.0, 30.0, 40.0 400ps, 1.3ns 10Hz, 100Hz, 200Hz, 1kHz, 5kHz, 10kHz, 15kHz, 55kHz, 100kHz Passive
Bright Microlaser Microchip SB1 Laser SB1-946 Pulsed DPSS Lasers, Microchip Lasers 946 0.004, 0.060, 0.070, 0.105 7.0, 12.0, 35.0 2ns 100Hz, 5kHz, 10kHz Passive
Sirius-532: Picosecond DPSS lasers Sirius GR Pulsed DPSS Lasers, Ultrafast Lasers 532 2.0 32.0 10ps Single shot to 1MHz Active
Sirius-532: Picosecond DPSS lasers Sirius IR Pulsed DPSS Lasers, Ultrafast Lasers 1064 5.0 60.0 10ps Single shot to 1MHz Active
SOL-06: 1064nm compact nanosecond laser SOL-1064 Pulsed DPSS Lasers 1064 4.0, 6.0, 10.0, 20.0, 30.0, 40.0 300.0, 450.0, 900.0, 1500.0, 2000.0 5ns - 35ns, 7ns - 35ns, 10ns - 40ns, 10ns - 50ns, 15ns - 60ns Single Shot to 100kHz Active
SOL-355 Pulsed DPSS Lasers 355 4.0 650.0 15ns - 35ns Single Shot to 100kHz Active
SOL-03-532: 532nm Nanosecond Laser SOL-532 Pulsed DPSS Lasers 532 3.0, 5.0, 10.0 200.0, 400.0, 650.0 15ns - 70ns, 10ns - 50ns, 10ns - 60ns Single Shot to 100kHz Active
VaryDisk E150 VaryDisk E150 Pulsed DPSS Lasers 1030 150.0 150000.0 2ps - 1ns 1kHz to 10kHz Active
Vento-1064 Pulsed DPSS Lasers 1064 16.0, 25.0, 40.0 600.0, 1000.0, 1500.0 500ps - 1.5ns 50kHz to 120kHz, 80kHz to 200kHz Active
Vento-532 Pulsed DPSS Lasers 532 8.0, 15.0, 20.0 300.0, 550.0, 750.0 500ps - 1.2ns 50kHz to 120kHz, 80kHz to 200kHz Active
Wedge-B-1064 Wedge-HB/XB 1064 Pulsed DPSS Lasers 1064 4.0 2000.0, 4000.0 1.5ns Single shot to 1kHz, Single shot to 2kHz Active
Wedge-B-266 Wedge-HB/XB 266 Pulsed DPSS Lasers 266 0.300, 0.500 150.0, 500.0 1.5ns, 1.8ns Single shot to 2kHz Active
Wedge-B-355 Wedge-HB/XB 355 Pulsed DPSS Lasers 355 0.400, 0.600 200.0, 600.0 1.2ns, 1.5ns Single shot to 1kHz, Single shot to 2kHz Active
Wedge-B-532 Wedge-HB/XB 532 Pulsed DPSS Lasers 532 2.0 1000.0, 2000.0 1.5ns Single shot to 1kHz, Single shot to 2kHz Active
Wedge-F-1064 Wedge-HF/XF 1064 Pulsed DPSS Lasers 1064 1.5, 4.0 70.0, 180.0 400ps - 1.5ns, 400ps - 1.6ns, 700ps - 2.5ns 10kHz to 100kHz, 50kHz to 200kHz Active
Wedge-F-266 Wedge-HF/XF 266 Pulsed DPSS Lasers 266 0.050, 0.180 5.0, 15.0 700ps - 1500ps, 400ps - 700ps 10kHz to 50kHz Active
Wedge-HF-355: 355nm compact nanosecond laser Wedge-HF/XF 355 Pulsed DPSS Lasers 355 0.800 40.0 500ps - 1ns 10kHz to 50kHz Active
Wedge-F-532 Wedge-HF/XF 532 Pulsed DPSS Lasers 532 0.500, 1.5, 2.0, 4.0 30.0, 40.0, 80.0, 120.0 500ps - 2ns, 700ps - 2ns, 400ps - 1.5ns, 400ps - 1ns 10kHz to 100kHz, 50kHz to 200kHz, Single shot to 10kHz Active
Wedge-XB 1572 Pulsed DPSS Lasers 1572 0.800 8000.0 2.5ns 1kHz Active
Wedge-XB 3um Pulsed DPSS Lasers 3106 0.200 100.0 3ns Single shot to 2kHz Active

FL-P Series

1um 1.5um Pulsed Fiber LasersThe FL-P series offers a variety of standard and custom pulsed fiber laser options. Available in both OEM and Turnkey formats, our 1um and 1.5um fiber lasers are manufactured to Telcordia standards and can be modified to meet your applications requirements. With available average powers up to 10W at 1um and 1.5um, peak powers up to 25kW, pulse widths in the range of 200ps to 100ns, and available options such as pulse monitoring, internal and external triggering, TTL or LVDS input signals, extended operating temperature range, and a robust design, our pulse series of fiber lasers are suitable for a wide range of applications. Customized configurations are available upon request.

Aero Series

Aero Laser by Bright SolutionsThe Aero Series is a high-energy DPSS laser that operates at less than 15 nanoseconds with multiple wavelength options including 266, 355, 532, and 1064nm. This series provides unparalleled precision and accuracy in even the most challenging environments. All models come enclosed in an extremely compact and ruggedized single unit with a conductively cooled heatsink with a water-cooled option. It comes with available options for beam expanding and collimating optics. This laser series is ideal for applications like LIBS, spectroscopy, and Atmospheric LIDAR.

Airtrac-MIL Series

AIRTRAC-LD

The AIRTRAC-MIL series is a ruggedized, high-shock, ultra-compact, actively q-switched, low-SWaP, DPSS laser, available with >90 mJ of pulse energy. Fully compliant NATO STANAG 3733 configurations for laser designation are available in a complete system weighing less than 1 lb. The athermal design of the AIRTRAC ensures high laser pulse energy, stable performance over the full temperature range with low beam divergence.

Alcor Series

Alcor

The Alcor series is the most advanced femtosecond fiber laser emitting at 920 nm or 1064 nm, designed explicitly for multiphoton microscopy, with the 920-1 & 920-2 providing the best performance on the market with ultrashort, clean pulses, all at a competitive price. Our lasers offer high pulse energy, short and clean pulses, and ultimate peak powers. With an ultra-compact, robust, and air-cooled design, our lasers are highly stable and reliable with low maintenance. Our XSight and FLeX fiber external modules allow for precise power control and gating and GDD precompensation. The Alcor series provides a complete and reliable solution for multi-photon microscopy, with seamless OEM integration.

Altair Series

Altair: Femtosecond Laser

The ALTAIR series produces high average powers up to 20W and ultrashort femtosecond pulses of <150 fs (<250 fs for VERSA configuration) at a high repetition rate of 80 MHz (others available). Ideal for bioimaging/biophotonics applications such as multiphoton microscopy, the ALTAIR provides high stability and excellent beam quality due to its mode-locked fiber design. It offers a range of options such as GDD pre-compensation, custom wavelengths, harmonics, repetition rates, and more. With a simplified fiber design that requires little to no maintenance compared to DPSS and Ti:Sapphire counterparts, the ALTAIR is the preferred solution for both OEM and researchers in the microscopy and life sciences fields.

Antares Series

Antares

The ANTARES is a series of high-energy picosecond lasers designed for ease-of-use and integration in biophotonics and nonlinear spectroscopy applications. With a narrow linewidth, high repetition rate up to 80 MHz, excellent beam quality, and average powers from 1W to 40W at 1030 nm or 1064 nm, ANTARES is ideal for high-speed nonlinear spectroscopy applications such as CARS and FRET microscopy. Additional options include fine-tuning PRF synchronization, ultra-narrow linewidth, second and third harmonic options, custom repetition rates, and more.

CEUV Series

R0Z2-Image-Compact-Efficient-UV-LaserThe CEUV series is a commercial line of compact and efficient DPSS laser sources, capable of operating over a wide range of pulsing conditions (duty-cycle and PRF), in a low SWaP package, with average power up to ≈5W @ 266nm, 10W @ 355nm or 532nm, 20W @ 1064nm. This series of DPSS lasers provides a combination of compact, efficient, and high-power performance in a rugged design suitable for harsh environments and airborne applications. The design has been tested in brassboard hardware and a prototype is being developed.

Diadem Series

DIADEM Series

The DIADEM series is a compact, versatile, air-cooled, high-energy, ultrafast femtosecond laser, operating at 1030 or 1064 nm for advanced micro-machining applications. Available with up to 40µJ of pulse energy, pulse widths down to ≈ 400 fs, an M² < 1.2, and single-shot up to 2MHz repetition rate, the DIADEM has many pulse control features such as adjustable pulse duration, selectable repetition rate from 40 MHz down to single-shot, or fine pulse energy tuning so that pulses can be emitted in various modes (on demand via external signal, burst of pulses with configurable pulse separation). A 1300 nm version is also available for deep brain imaging.

Jenlas Fiber ns

The JenLas Fiber ns series is a versatile line of fiber lasers designed for OEM integrators, researchers, and applications specialists working with material processing applications. Available in 20, 30, 55, and 100W power configurations, this air-cooled laser series boasts reliable, industry-tested fiber laser technology and an adjustable pulse length. With pulse duration settings ranging from 50 to 200 nanoseconds and peak pulse powers of up to 8kW, this series offers improved performance and extended control capabilities, allowing for pulse repetition rates and pulse lengths to be changed by choosing different modes. The JenLas Fiber ns series is available with a complete set of customizable accessories, including laser controllers, beam expanders, and air or water cooling.

MicroMake Series

MicroMake: Micromachining Laser SystemMicroMake Series from Bright System is an integrated compact laser micromachining system for high precision and resolution applications such as ablation and cutting of programmable arbitrary shapes. The sub-nanosecond MicroMake series is a flexible platform capable of >35kW of peak power and processing speeds up to 40mm/second. The system includes all the needed devices for direct laser micro-processing in a single monolithic air-cooled configuration. Live microscope imaging of the sample is offered during all process phases for alignment and immediate quality check. All these features perfectly suit a large variety of materials utilized in the fields of microelectronic circuits, displays fabrication and correction, biomedical device machining and optical substrates microprocessing.

neoMOS Series

neoMOS 700fsThe neoMOS ultrashort pulse laser series is a reliable and low maintenance system designed for 24/7 industrial use. Its ultra-compact laser head has the smallest footprint available, making it easy to integrate into different systems. The laser systems are highly flexible and can be customized to meet specific needs, providing a wide range of laser parameters and pulse durations. With available pulse durations between 700fs and 70ps, repetition rates from single-shot to 80MHz, up to 500µJ pulse energy, average output powers up to 100W, multi-megawatt peak powers, and perfect TEM00 beam quality, these lasers can tackle many applications and are ideal for processing demanding materials such as transparent glasses and plastics.

Nps Series

Nps-1064-10

The NPS series of ultrafast lasers is the ultimate solution for OEM integrators and researchers working with nonlinear optics applications like OPO pumping and narrowband Raman spectroscopy. The NPS series boasts remarkable features such as up to 10W average output power, <7ps pulse width, and a 40MHz repetition rate. The transform-limited operation, with a spectral width of <0.3nm, and accurate central wavelengths make these lasers a suitable candidate for highly efficient amplification by Nd-doped DPSS amplifiers.

Onda Series

Onda 532nm: 532nm High Energy Laser

The Onda series is a DPSS nanosecond OEM laser platform designed for high-end applications requiring excellent beam quality and high peak power in materials such as metals, glass, plastics, and various delicate and hard materials. This compact and easy to use laser series is available in wavelengths of 266, 355, 532, and 1064nm, with an extended operating temperature range and superior performance to cost ratio. The Onda seriesinternal optical layout and accurate temperature management enable high output energies without compromising the lifetime of the THG and FHG stages.

One Series

One-1030-100: 1030nm Miniature Q-Switched Laser

The One Series is a versatile, passively q-switched laser series designed specifically for OEM integrators and application specialists working with industrial and portable applications like materials processing and airborne LIDAR. With its compact size and ability to operate at a fundamental wavelength of 1030nm, this series offers exceptional performance for a range of applications. The One Series can be configured in a fixed operational rep rate configuration, or an externally triggerable configuration. Available in both high energy configurations (up to 100uJ) and high average power configurations (up to 3W), the One series is a reliable choice for any application.

Q-TUNE-IR Series

Q-TUNE-IRThe Q-TUNE-IR series is the perfect high peak power, coherent, DPSS light source for researchers working with infrared spectroscopy applications. This series uses an Optical Parametric Oscillator (OPO) to produce tunable wavelength in the 1380 – 4500 nm range with a linewidth less than 10 cm-1, achieving > 6.5mJ of pulse energy @ 3500nm for the F-10 configuration (> 2mJ @ 3500nm for C-10) with a 10Hz repetition rate. The Q-TUNE-IR requires little maintenance, with all laser electronics integrated into the housing, including an air-cooling system, eliminating the need for chillers or large power supplies, all while providing a guaranteed pump diode lifetime greater than 2 giga-shots.

Q-TUNE Series

Q-TUNE-IR

The Q-TUNE series is a highly efficient, tunable wavelength laser designed for researchers working with temporally resolved spectroscopy, metrology, photo-acoustic imaging, and remote sensing applications. This laser uses an optical parametric oscillator (OPO) to produce a tunable wavelength range of 410-2300 nm with a linewidth narrower than 6 cm-1, which can be extended to 210-410 nm with an optional second harmonic generator. With a pulse duration shorter than 5ns and an upper repetition rate of 100Hz, the Q-TUNE series provides a perfect coherent light source for precise scientific measurements.

Q-SHIFT Series

Q-Shift SeriesThe Q-SHIFT series of Q-switched DPSS lasers is designed for researchers and application specialists working in micromachining, dermatology, LIDAR, time-resolved laser spectroscopy, and LIBS applications. With its built-in nonlinear wavelength conversion stage, this series allows the production of unconventional fundamental DPSS wavelengths, including 1163, 1177, 1300, 1317, 1551 and 1571 nm options, making it an ideal choice for those seeking wavelengths that are not accessible with conventional solid-state laser sources. With the optional harmonics generator, it is possible to generate up to the 4th harmonic for each fundamental wavelength, providing even more versatility.

Q-Spark

Quantas-Q-SPARK-266: High energy, compact, nanosecond, DPSS laser

The Q-SPARK series is an air-cooled, diode-pumped, Q-switched laser designed for researchers and application specialists working with ablation, LIDAR, remote sensing, and LIBS applications. The laser produces sub-nanosecond or nanosecond pulses with peak power up to 20 MW and pulse energies up to 10 mJ, making it ideal for a wide range of applications. With a short <1.5 ns pulse, compact air-cooled package, and innovative water-free laser crystal end-pumping technology, the Q-SPARK series delivers high-quality, low divergence, Gaussian-like laser beams.

Q1 Series

Quantas-Q1-211: High energy, compact, nanosecond, DPSS laser

The Q1 series is a compact, energy-efficient, diode pumped, air-cooled, Q-switched laser available at 1064 and 1053nm with up to 45 mJ of pulse energy and rep rates up to 50Hz. The high peak powers and low divergence of the Q1 series enable efficient harmonic conversion through the 5th harmonic (213 or 211nm). The innovative design results in a user-friendly, turnkey system that requires little maintenance, and the laser’s variable pulse repetition rate and built-in sync pulse generator provide flexibility for triggering user equipment.

Q2 Series

Quantas Q2 QLI

The Q2 series is a diode-pumped, fully air-cooled, Q-switched laser designed for a wide range of applications that require high peak power pulses. Its innovative water-free laser crystal end-pumping technology produces Gaussian-like, low divergence laser beams with high peak powers, allowing for efficient harmonics conversion through the 5th harmonic. This versatile platform can be configured in many ways, including up to 80mJ pulse energy at 10 Hz pulse repetition rate or up to 20mJ at 100 Hz. The laser can emit either 1053 nm or 1064 nm wavelength, and in the short cavity configuration, pulse duration can be reduced by 50% in comparison to standard configuration.

Q2HE Series

Quantas-Q2HE-211: High energy, compact, nanosecond, DPSS laser

The Q2HE series is a highenergy, q-switched, diode-pumped solid-state (DPSS) laser series, available in either 1053nm or 1064nm fundamental wavelengths, with optional 2nd, 3rd, 4th, or 5th harmonic generation. This air-cooled series of lasers is designed for a wide range of applications that require high peak power pulses. Due to a short laser cavity, excellent thermal properties of the crystal, and an innovative water-free crystal cooling technology, the Q2HE series can deliver up to 120mJ of pulse energy and/or up to 4W average output power. This advanced laser design results in a compact, user-friendly turnkey system that requires little maintenance.

Microchip Series

Bright Microlaser Microchip SB1 Laser

The Microchip series is a line of ultra-compact, passively q-switched, single longitudinal mode (SLM), narrow linewidth, DPSS lasers that offer exceptional performance in a compact form factor. The lasers feature pulse durations ranging from 400 ps to 2 ns, energy levels up to 80 µJ, and repetition rates up to 100 kHz. Available in wavelengths from the UV to the NIR, this series is designed for OEM integrators and researchers working with LIDAR, 3D scanning, LIBS, night vision, and more. The lasers offer both nanosecond and picosecond options and are interchangeable with the same form factor and electrical and software interfaces across wavelengths, making them a flexible and versatile solution.

Sirius Series

Sirius-532: Picosecond DPSS lasers

The SIRIUS series is a very compact, high-energy hybrid ultrafast laser for advanced micro-machining applications and supercontinuum pumping, offering over 60µJ and > 5 W @ 1064 nm, with pulses below 10 ps from single shot to 1MHz and an M² of < 1.2. SIRIUS is a fully configurable laser offering various pulse generation modes: selectable pulse durations and repetition rates, burst, gating and fine energy control. This laser series is specifically designed to allow for ergonomic and user-friendly operation. Also available in green or UV wavelengths, SIRIUS is ideally suited for selective ablation, electronics, and photonic applications.

SOL Series

SOL-03-532: 532nm Nanosecond Laser

The SOL series is the most compact, air-cooled, Q-switched DPSS nanosecond laser available in the power range from 4W to 40W @ 1064nm. Available @ 1064nm, 532nm, and 355nm, the SOL laser series offers excellent beam quality and high peak power, capable of up to 10W and 650µJ at 532nm and 4W @ 355nm, making it the ideal source for the most demanding industrial and scientific applications. With a rugged, compact, lightweight, and easy to use single unit design, the SOL laser is easy to integrate into micro-machining and marking applications, providing superior operational flexibility and performance/cost ratio.

VaryDisk Series

VaryDisk E150The VaryDisk Series is a high-energy, multi-milli-Joule laser system suitable for laboratory investigations or industrial use. This thin disk regenerative amplifier can amplify femtosecond, picosecond, or nanosecond pulses with amplification factors up to 10⁶. With a range of output specifications to choose from, including multiple seed lasers, customers can select the ideal configuration to meet their needs. The base configuration offers up to 150 W average power @ 1030 nm, 15 – 150 mJ pulse energy, 1 ns pulse width (compressible to < 2 ps), and a repetition rate range of 1 kHz to 10 kHz.

Vento Series

Vento-532-7: 532nm Picosecond DPSS Laser

The Vento series is a compact and ruggedized sub-nanosecond DPSS laser series designed for OEM integrators, application specialists, and researchers working with scientific and industrial applications such as precision LIDAR and materials processing. With pulse durations down to 500 ps and repetition rates up to 200 kHz, this laser series produces high average power of up to 25 W @ 532 nm and up to 40 W @ 1064 nm. The Vento series features beam expanding and collimating optics, low jitter option, extended operating temperature range, pulse energy modulation up to IP68 Package, circular polarization, remote control cbox and software interface, air and water-cooled options, and AC-DC power supply.

Wedge Series

Wedge-XF-1064: 1064nm Picosecond Laser

The Wedge series is a line of DPSS lasers designed specifically for OEM applications such as micro machining of hard and soft materials, specialty marking, glass and crystal engraving, LIDAR, LIBS, spectroscopy, and medical diagnostics. These diodepumped lasers, based on proprietary fast Q-switching technology, are compact, sealed, and monolithic which makes them insensitive to vibrations and harsh environments. With high peak powers and relatively low energy and heat generation, they allow efficient ablation and non-linear interaction with most materials. The compact and lightweight package is a great benefit in LIDAR and other aerospace applications, while short pulses provide extremely precise time-of-flight measurements.

Pulsed Lasers FAQs
What is a Pulsed Laser?

A pulsed laser is any laser that does not emit a continuous-wave (CW) laser beam. Instead, they emit light pulses at some duration with some period of ‘off’ time between pulses and a frequency measured in cycles per second (Hz). There are several different methods for pulse generation, including passive and active q-switching and mode-locking. Pulsed lasers store energy and release it in these pulses or energy packets. This pulsing can be very beneficial, for example, when machining certain materials or features. The pulse can rapidly deliver the stored energy, with downtime in between, preventing too much heat from building up in the material. If you would like to read more about q-switches and the pros and cons of passive vs active q-switches, check out this blog “The Advantages and Disadvantages of Passive vs Active Q-Switching,” or check out our Overview of Pulsed Lasers section on our Lasers 101 Page!

What is a Pulsed Laser?

A pulsed laser is any laser that does not emit a continuous-wave (CW) laser beam. Instead, they emit light pulses at some duration with some period of ‘off’ time between pulses and a frequency measured in cycles per second (Hz). There are several different methods for pulse generation, including passive and active q-switching and mode-locking. Pulsed lasers store energy and release it in these pulses or energy packets. This pulsing can be very beneficial, for example, when machining certain materials or features. The pulse can rapidly deliver the stored energy, with downtime in between, preventing too much heat from building up in the material.

What is the best laser for LIDAR?

There are actually numerous laser types that work well for various LIDAR and 3D Scanning applications. The answer comes down to what you want to measure or map. If your target is stationary, and distance is the only necessary measurement, short-pulsed lasers, with pulse durations of a few nanoseconds (even <1ns) and high pulse energy are what you’re looking for. This is also accurate for 3D scanning applications (given a stationary, albeit a much closer target), but select applications can also benefit from frequency-modulated, single-frequency (narrow-linewidth) fiber lasers. If your target is moving, and speed is the critical measurement, you need a single-frequency laser to ensure accurate measurement of the Doppler shift. If you want to learn more about the various forms of LIDAR and the critical laser source requirements, check out our LIDAR page for a list of detailed articles, as well as all the LIDAR laser source products we offer. Get more information from our Lasers 101, Blogs, Whitepapers, FAQs, and Press Release pages in our Knowledge Center!

What is the best laser for LIDAR?

There are actually numerous laser types that work well for various LIDAR and 3D Scanning applications. The answer comes down to what you want to measure or map. If your target is stationary, and distance is the only necessary measurement, short-pulsed lasers, with pulse durations of a few nanoseconds (even <1ns) and high pulse energy are what you’re looking for. This is also accurate for 3D scanning applications (given a stationary, albeit a much closer target), but select applications can also benefit from frequency-modulated, single-frequency (narrow-linewidth) fiber lasers. If your target is moving, and speed is the critical measurement, you need a single-frequency laser to ensure accurate measurement of the Doppler shift.

What is the best laser for tattoo removal?

Similar to laser hair removal, laser tattoo removal utilizes a process known as selective photothermolysis to target the embedded ink in the epidermis and dermis.  Photothermolysis is the use of laser microsurgery to selectively target tissue utilizing specific wavelengths of light to heat and destroy the tissue without affecting its surroundings.  In laser tattoo removal this is accomplished by using a focused q-switched laser with a fluence of approximately 10 J/cm2, to heat the ink molecules locally.  Since the q-switched laser’s pulse duration (100 ps to 10 ns) is shorter than the thermal relaxation time of the ink molecules it prevents heat diffusion from taking place.  In addition to minimizing damage to the surrounding tissue, this rapid localized heating results in a large thermal differential, resulting in a shock wave which breaks apart the ink molecules. If you would like more details on pulsed lasers for tattoo removal applications, see our Aesthetics Lasers page here! Get more information from our Lasers 101, Blogs, Whitepapers, and FAQ pages in our Knowledge Center!

What is the best laser for tattoo removal?

Similar to laser hair removal, laser tattoo removal utilizes a process known as selective photothermolysis to target the embedded ink in the epidermis and dermis.  Photothermolysis is the use of laser microsurgery to selectively target tissue utilizing specific wavelengths of light to heat and destroy the tissue without affecting its surroundings.  In laser tattoo removal this is accomplished by using a focused q-switched laser with a fluence of approximately 10 J/cm2, to heat the ink molecules locally.  Since the q-switched laser’s pulse duration (100 ps to 10 ns) is shorter than the thermal relaxation time of the ink molecules it prevents heat diffusion from taking place.  In addition to minimizing damage to the surrounding tissue, this rapid localized heating results in a large thermal differential, resulting in a shock wave which breaks apart the ink molecules.

What is the best laser type for multi-photon microscopy?

Multiphoton excitation requires high peak power pulses. Previously, wavelength tunable Ti:Sapphire lasers dominated this area, leading to the development of standard methods using a conventional pulse regime with typically 100-150 fs pulse duration, 80 MHz repetition rate, and watt level average power with specific wavelengths such as 800 nm, 920 nm, and 1040-1080 nm. Recently, femtosecond pulsed fiber lasers have started becoming the optimal solution due to their low relatively low fluence, limiting damage to living samples. Other advantages provided by fs fiber lasers include a more attractive price point, very compact and robust format, high electrical efficiency, high reliability, and less maintenance of cost of ownership. If you would like more details on why fs fiber lasers are becoming the optimal choice for multi-photon excitation applications, read this article: “Higher Power fs Fiber Lasers to Image Better, Deeper & Faster.” Get more information from our Lasers 101, Blogs, Whitepapers, FAQs, and Press Release pages in our Knowledge Center!

What is the best laser type for multi-photon microscopy?

Multiphoton excitation requires high peak power pulses. Previously, wavelength tunable Ti:Sapphire lasers dominated this area, leading to the development of standard methods using a conventional pulse regime with typically 100-150 fs pulse duration, 80 MHz repetition rate, and watt level average power with specific wavelengths such as 800 nm, 920 nm, and 1040-1080 nm. Recently, femtosecond pulsed fiber lasers have started becoming the optimal solution due to their low relatively low fluence, limiting damage to living samples. Other advantages provided by fs fiber lasers include a more attractive price point, very compact and robust format, high electrical efficiency, high reliability, and less maintenance of cost of ownership.

What is the difference between active and passive q-switching?

There are a wide variety of q-switch technologies, but the technique as a whole can be broken down into two primary categories of q-switches, passive and active. Active q-switches could be a mechanical shutter device, an optical chopper wheel, or spinning mirror / prism inside the optical cavity, relying on a controllable, user set on/off ability. Passive q-switches use a saturable absorber, which can be a crystal (typically Cr:YAG), a passive semiconductor, or a special dye, and automatically produce pulses based on it’s design. Both passive and active q-switching techniques produce short pulses and high peak powers, but they each have their pros and cons. When choosing between actively q-switched and passively q-switched lasers, the key is to understand the tradeoffs between cost/size and triggering/energy and decide which is best for your particular application. Read more about these tradeoffs in this article: “The Advantages and Disadvantages of Passive vs Active Q-Switching.” Get more information from our Lasers 101, Blogs, Whitepapers, FAQs, and Press Release pages in our Knowledge Center!

What is the difference between active and passive q-switching?

There are a wide variety of q-switch technologies, but the technique as a whole can be broken down into two primary categories of q-switches, passive and active. Active q-switches could be a mechanical shutter device, an optical chopper wheel, or spinning mirror / prism inside the optical cavity, relying on a controllable, user set on/off ability. Passive q-switches use a saturable absorber, which can be a crystal (typically Cr:YAG), a passive semiconductor, or a special dye, and automatically produce pulses based on it’s design. Both passive and active q-switching techniques produce short pulses and high peak powers, but they each have their pros and cons. When choosing between actively q-switched and passively q-switched lasers, the key is to understand the tradeoffs between cost/size and triggering/energy and decide which is best for your particular application.

What type of laser is used for LIBS?

A laser source used for LIBS must have a sufficiently large energy density to ablate the sample in as short a time possible. Typically, pulsed DPSS lasers take center stage here. However, it’s been shown that pulsed fiber lasers can also be a great option. For example, you could utilize fiber lasers to measure detection limits as low as micrograms per gram (µg/g) for many common metals and alloys, including aluminum, lithium, magnesium, and beryllium. Analytical performances showed to be, in some cases, close to those obtainable with a traditional high-energy Nd:YAG laser. The beam quality of fiber lasers, in conjunction with longer pulse widths, resulted in significantly deeper and cleaner ablation craters. If you want to learn more about LIBS and ideal laser sources, check out either this blog: “OEM Fiber Lasers for Industrial Laser Induced Breakdown Spectroscopy,” or this blog: “Laser Induced Breakdown Spectroscopy (LIBS) in Biomedical Applications.” Get more information from our Lasers 101, Blogs, Whitepapers, FAQs, and Press Release pages in our Knowledge Center!

What type of laser is used for LIBS?

A laser source used for LIBS must have a sufficiently large energy density to ablate the sample in as short a time possible. Typically, pulsed DPSS lasers take center stage here. However, it’s been shown that pulsed fiber lasers can also be a great option. For example, you could utilize fiber lasers to measure detection limits as low as micrograms per gram (µg/g) for many common metals and alloys, including aluminum, lithium, magnesium, and beryllium. Analytical performances showed to be, in some cases, close to those obtainable with a traditional high-energy Nd:YAG laser. The beam quality of fiber lasers, in conjunction with longer pulse widths, resulted in significantly deeper and cleaner ablation craters.

Which IR laser is best for laser target designation?

There are many different types of laser designation systems used by the military today. Still, they all share the same basic functionality and outcome. At a glance, the laser requirements seem relatively straightforward. The laser needs to be invisible to the human eye, and it needs to have a programmable pulse rate. Still, when you look in more detail, many small factors add up to big problems if not appropriately addressed. Excellent divergence and beam pointing stability, low timing jitter, and rugged, low SWaP design are all critical features of a good laser designation source. Read more on these critical features in this article: “What are the Critical Laser Source Requirements for Laser Designation?” Get more information from our Lasers 101, Blogs, Whitepapers, FAQs, and Press Release pages in our Knowledge Center!

Which IR laser is best for laser target designation?

There are many different types of laser designation systems used by the military today. Still, they all share the same basic functionality and outcome. At a glance, the laser requirements seem relatively straightforward. The laser needs to be invisible to the human eye, and it needs to have a programmable pulse rate. Still, when you look in more detail, many small factors add up to big problems if not appropriately addressed. Excellent divergence and beam pointing stability, low timing jitter, and rugged, low SWaP design are all critical features of a good laser designation source.
