A picosecond laser is a type of laser that emits pulses of light with a duration of one picosecond (10^-12 seconds).
These extremely short pulses of light allow for high precision and minimal heat-affected zone, making them ideal for a wide range of applications, such as material processing, medical treatments, and scientific research.
Picosecond lasers are one of the most diverse categories of pulsed lasers available on the market today since picosecond pulses can be generated by q-switching, gain switching, and mode locking. Picosecond pulses can be produced from diode-pumped solid-state (DPSS) lasers, fiber lasers, and microchip lasers allowing for an extensive wavelength range from the ultraviolet through the infrared region.
Additionally, this broad range of lasers enables pulse energies in the nJ, µJ, and mJ levels with pulse repetition rates varying from Hz to MHz. The high peak power and short pulse widths (pulse duration) of these lasers are ideal for a wide range of applications especially for material processing and micromachining industrial applications such as laser texturing, trimming, and drilling.
Picosecond Laser Benefits
High precision: The extremely short duration of picosecond laser pulses allows for precise targeting of material and fine features while minimizing damage to surrounding areas.
Minimal heat affected zone: Picosecond lasers generate less heat than longer pulse lasers, which reduces the amount of material affected by the laser and minimizes the risk of thermal damage.
High ablation rate: Picosecond lasers can remove material at a faster rate than longer pulse lasers, making them suitable for high-speed machining and cutting applications.
Improved surface finish: Picosecond lasers can produce a smoother surface finish than longer pulse lasers, which is beneficial for certain applications such as medical devices or electronic components.
Versatility: Picosecond lasers have a wide range of applications, including material processing, medical treatments, scientific research, and more.
Wide range of materials: Picosecond lasers can be used with a wide range of materials, including metals, plastics, ceramics, and semiconductors.
Our Picosecond Products
RPMC offers ps pulsed lasers at various levels of integration from OEM to turn-key, benchtop, laboratory and research laser systems. We group our picosecond lasers into a few different types including Pulsed DPSS Lasers, Pulsed Fiber Lasers, Ultrafast Lasers, Microchip Lasers, and DPSS Amplifiers.
Our lasers are available with ultraviolet (UV), Green, near-infrared (NIR), and short-wave infrared (SWIR) wavelength options, including 266 nm, 355 nm, 532 nm, 1030 nm, 1064 nm, 1100 nm, and 1540 nm. Average output powers for these picosecond laser options range from a few mW (milliwatts) up to 150 W (watts), and pulse energy options ranging from 25 nJ (nanojoules) up to 150 mJ (millijoules).
On this page, you will find picosecond pulse duration options from 750 ps down to 2 ps, as well as nanosecond (ns) and femtosecond (fs) pulse width options. A wide range of repetition rate options are available from single shot up to 80 MHz.
Our Picosecond Laser Experience
RPMC Lasers is your preferred Picosecond Laser Supplier, partnering with industry-leading and emerging manufacturers. We have been in business for over 25 years, providing researchers and OEM integrators with the best laser solution for their application. We have fielded 1000s of units for many different applications from micromachining to LIDAR and Bathymetry to medical applications such as tattoo removal and ablation-based surgical procedures.
Deeper Dive into Picosecond Lasers
Peak Power and Average Power in ns and Sub-ns Lasers:
The extremely high peak power levels achievable by pulsed laser sources are among the main reason for their success in many of the applications which have emerged in the last decades. Therefore, a precise estimation of the laser peak power, given other operational parameters such as average power, pulse duration, and repetition rate, is fundamental to select the best option for a particular application among the different commercial alternatives. In principle, it is quite simple to calculate the peak power, considering the actual temporal profile of the laser pulse. By assuming a train of continuously repeated, periodical, square pulses with repetition rate fR, pulse duration tP and average power PAV, the pulse energy EP and peak power PP calculations are trivial, with pulse energy provided by the ratio between average power and repetition rate and peak power provided by the ratio between energy and pulse duration:
The Advantages and Disadvantages of Passive vs Active Q-Switching:
Triggering – One of the significant disadvantages of passive q-switching is that you have no control over when the laser actually pulses. The laser’s pulse repetition rate will be solely dependent on the when the absorber saturates. This is very much akin to a free-running system which not only cannot be controlled but also can experience pulse to pulse variability or jitter. An actively q-switched laser, on the other hand, provides the ability to trigger the pulse at a specific time and with a particular pulse repetition rate. This makes it far easier when synchronizing the laser to other instrumentation, such as a kinematic arm for laser machining or a spectrometer for laser-induced breakdown spectroscopy (LIBS). It should be noted though that most passively q-switched lasers do contain an internal photodiode that can be used to synchronize to an external device, but this not nearly as flexible as the ability to trigger in.
Pulse Energy – While some passive q-switches are capable of producing rather large, mJ level, laser pulses, in general active q-switching tends to lead to far larger pulse energies. This is because the q-switch can be actively controlled to allow for the maximum shutter time needed for full population inversion. As a result, the q-switch can be timed to open with the same period as the decay lifetime of the gain medium’s metastable state resulting in the maximum possible pulse energy. By contrast with a passive q-switch once the absorber has saturated it will release all of the stored energy regardless of whether or not maximum population inversion has been achieved.
Why is a Low Jitter Feature Important in Actively Q-Switched DPSS Lasers?
In actively Q-switched lasers, the user controls the pulsed laser output, so that no laser pulse emission occurs without providing a proper input signal, aka “the trigger”. Due to the trigger signal propagation through the interface electronics, the Q-switch driver chain, and the laser resonator build-up time, a time delay (Td) is present between the externally-supplied trigger signal and the actual laser pulse emitted by the laser source. The Td can show fluctuations if any electronics or optics involved in the pulse generation process have a functional variance in time.
The parameter Td is very relevant in the timing management of some applications. You must consider both the time delay (Td) and a time jitter (Tj), which is a statistical variation of the time delay depending mostly on:
electrical noise in the trigger-chain
pulse-to-pulse fluctuation of trigger-chain electrical parameters
laser pulse build-up time-mechanism and associated fluctuations.
fluctuation of rising (-falling) edge temporal profile of the trigger signal
Because of the jitter phenomena, the actual value of the time delay is statistically altered. Therefore, the laser pulse emission event happens (in the vast majority of cases) inside a normal time distribution, defined by an average time delay Td and a standard deviation value Tj (i.e 68.2 out of 100 pulses develop in the time interval Td ±Tj).
What is a Thin Disk Laser, and What Advantages do They Offer?
A thin disk laser is a type of diode-pumped solid-state (DPSS) laser technology in which the gain medium is comprised of a thin disk of typically Yb:YAG crystal. The thickness of one of these disks (typically 150µm to 200µm thick) is substantially smaller than the beam diameter. This feature allows not only the ability to easily scale up power via pump beam diameter, but also provides a large surface area for heat dissipation. For example, the VaryDisk Series platform is a high energy, multi-milli-Joule laser system for laboratory investigations or industrial use. This is a thin disk regenerative amplifier for amplification of femtosecond, picosecond or nanosecond pulses with amplification factors in the order of 10⁶.
The picosecond laser benefits make them a good fit for many applications. Typically, various forms of micromachining and material processing come to mind, as mentioned above. The reduction of HAZ and elimination of post-processing makes these lasers desirable for processing of many materials, especially sensitive materials, including medical devices, where rough edges and pits can lead to collection and growth of bacteria, for example. Pico lasers also allow for very fine features to be machined without deformation of the surrounding material. The same is true for femtosecond lasers. However, the picosecond laser cost tends to be much more attractive, with high peak powers and higher average powers available at a lower price, and a less complicated system.
Some other applications that benefit from high peak power picosecond pulsed lasers include various medical applications, such as tattoo removal, pigment removal / pigment reduction, hair removal, and other ablation-based surgical procedures. Laser microscopy, optical parametric oscillators (OPO) pumping, time-of-flight (ToF) LIDAR, pump-probe measurements, and optical fiber communications all benefit from the used of picosecond pulsed lasers. Below we will detail some picosecond laser application examples and links to more in-depth articles:
Laser Material Processing:
Laser material processing includes a wide range of applications including laser scribing, laser drilling, laser cutting, laser marking, thin film removal, laser surface treatment, and much more. One thing most of these applications share is the benefit of utilizing very short light pulses in the picosecond and short nanosecond range (as well as femtosecond for certain applications), which provide high peak power for a particular pulse energy.
Typically, nanosecond pulses are too long, as there is a significant build up of heat in the surrounding material, causing a more prominent heat affected zone (HAZ), which can damage, warp, burn, or discolor the surrounding area. This increased HAZ is undesirable, as post processing (cleaning) is then required, and furthermore, depending on the requirements and specifications of the material or product, significant heat build up can cause catastrophic failure of the part, its particular features, or simply render it unusable, for example with medical products that need clean, smooth features.
Picosecond Ultrafast Lasers
Pico lasers that produce less than 10 picoseconds pulses belong to the category of ultrafast lasers or ultrashort pulse lasers. Ultrafast Lasers are ideal for the cold ablation of any material, including metals, ceramics, polymers, composites, coatings, glass, plastics, diamonds, and PET. Ultrafast lasers can even operate on layered substrates. Cold ablation allows for material to be removed without heating the residual matter. Thus, femtosecond fiber lasers will not produce heat affected zones (HAZ), splatter, or significant recast. Additionally, these ultrafast picosecond lasers will eliminate the need for any post-processing.
Picosecond vs Femtosecond Lasers:
In relation to femtosecond laser sources, picosecond lasers are typically more cost-effective, providing a higher average output power at a lower price point. Laser micromachining applications often benefit from that extremely high quality results provided by femtosecond pulses. However, short picosecond pulses often provide perfectly acceptably results when the processing parameters are optimal, making picosecond lasers the preferred choice, if you do not require the ultra-fine features and exceptional edge quality that femtosecond lasers provide.
LIDAR Becoming the Future of Bathymetry:
As in most LIDAR systems designed for distance measurement, bathymetric LIDAR relies on time-of-flight determination for calculating the distance to the target. This is done by using a time-gated detector which is synchronized with a pulsed (typically picosecond or short-nanosecond range) laser source so that the round-trip time (Δt) can be determined. In traditional LIDAR, the range (R) to the target is then determined using the following equation, R = C × Δt/2, where C is the speed of light. In bathymetry though there is an added complication because you want to determine the depth of the water, not the distance from the transceiver to the water. Therefore, you need to measure both the distance to the surface of the water and the floor and take the difference between the two. This is typically done using a “multi-beam” approach, which takes advantage of the difference in absorption of the water at various wavelengths. As can be seen in the graph below, water has an absorption minima around 500 nm, meaning that green laser light will penetrate much deeper into the water than near-infrared light will.
Want to Minimize Your LIDAR Footprint, Cost, and Energy Consumption?
Doppler LIDAR is growing in popularity, for instance, in wind farms, where the rapid detection of extreme weather changes can prevent damage to the wind turbine. Traditional anemometer/wind vane devices are too slow to report drastic weather changes in time to avoid damage. Alternatively, implementing a network of single-frequency Doppler LIDAR sensors around a wind farm, in conjunction with highly accurate wind models, allows for much higher accuracy wind speed readings and faster response times. This rapid access to accurate data provides time to adjust the blade angle to optimize the efficiency without overloading the turbine.
As we covered extensively in “Single-Frequency Fiber Lasers for Doppler LIDAR,” if you want to measure both the speed at which an object is moving and its location, there is no better option than frequency modulated (FM) LIDAR. For this signal processing methodology to work, you need to maintain precise control over the laser frequency. While a wide variety of single-frequency lasers have been used in Doppler LIDAR research, the industry as a whole has adopted picosecond and short-nanosecond pulsed, single-frequency fiber lasers as the ideal light source.
Microchip Lasers: Fully Integrated Modules for LIDAR & 3D Scanning
LIDAR lasers are available in a vast range of configurations, tailored for different sets of end-use applications. The main determining factor for which type of LIDAR laser you need depends on whether your application is measuring a moving or stationary target. If your target is stationary, and distance is the only necessary measurement, short-pulsed lasers, with pulse durations of a few nanoseconds (even <1ns) and high pulse energy are what you’re looking for. This is also accurate for 3D scanning applications (given a stationary, albeit a much closer target), but select applications can also benefit from frequency-modulated, single-frequency (narrow-linewidth) fiber lasers. If your target is moving, and speed is the critical measurement, you need a single-frequency laser to ensure accurate measurement of the Doppler shift.
While the primary difference between traditional LIDAR and 3D scanning applications is the distance from the laser to the target, both sets of applications benefit from the features provided by high-quality microchip lasers. Lightweight and very compact modules, with low power draw, are perfect for integrating into portable devices for long battery life and increased mobility in the field. Excellent beam quality enables very small spot sizes and therefore, high peak power, incident upon the sample, for high-quality data collection. A simplistic design and low cost ensure a long lifetime of reliable performance, with reduced susceptibility to shock and vibration, without breaking your budget.
Laser Induced Breakdown Spectroscopy (LIBS) in Biomedical Applications:
As the name implies LIBS utilizes a focused laser beam to breakdown or ablate the sample. In this process, a microscopic portion of the sample is vaporized causing a momentary plasma to be formed. This causes all of the ionized elements in the plasma plume to emit light corresponding to their unique atomic energy levels. By collecting the light emitted from the induced plasma plume and directing into a spectrometer the measured lines can then be correlated with the presence and concentrations of the samples elemental structure. While the physical process is quite different it is often helpful to think of LIBS, as an optical analog to mass spectrometry.
From this description above it should be obvious that the laser source used must have a sufficiently large energy density to ablate the sample in as short a time possible. As a result, the vast majority of LIBS lasers are q-switched diode pumped solid state (DPSS) lasers, which typically provide millijoules of energy in a nanosecond to picosecond pulse duration. When focused down to a small spot, this allows the laser to quickly ablate the sample, and trigger the spectrometer to immediately start the acquisition process to collect the atomic emissions from the short-lived plasma plume.
Raman Spectroscopy: Why are Picosecond Pulses Superior to Femtosecond?
Raman-based spectroscopy, on the other hand, is an entirely different nonlinear technique, relying on the frequency shift experienced by laser radiation incident on a molecule, related to its rotational and vibrational modes. Not being related to electronic transitions, the Raman shift is relative concerning the irradiating wavelength, and therefore, unless pursuing coherent excitation, laser source tunability is not required. Raman-based spectroscopy, being a nonlinear process, usually requires ultrashort pulse generation (e.g., practical TPA set-ups usually require < 300 fs pulse duration). On the other hand, since the Raman gain is generally higher than TPA cross-sections, cheaper and simpler picosecond lasers could be efficiently employed in incoherent Raman spectroscopy. Furthermore, in Raman spectroscopy, the spectral resolution is related to the laser source bandwidth. Therefore, the narrower bandwidths of picosecond lasers represent a remarkable advantage over their femtosecond counterparts.
With 1000s of fielded units, and over 25 years of experience, providing researchers with the best laser solution for their application, our expert team is ready to help! Working with RPMC ensures you are getting trusted advice from our knowledgeable and technical staff on a wide range of laser products. RPMC and our manufacturers are willing and able to provide custom solutions for your unique application.
If you have any questions, or if you would like some assistance please Contact Us here. Furthermore, you can email us at [email protected]to talk to a knowledgeable Product Manager.
Alternatively, use the filters on this page to assist in narrowing down the selection of Picosecond lasers for sale. Finally, head to our Knowledge Center with our Lasers 101 page and Blogs, Whitepapers, and FAQ pages for further, in-depth reading.
Check out our Online Store: This page contains In-Stock products and an ever-changing assortment of various types of new lasers at marked-down/discount prices.
The FL-P series offers a variety of standard and custom pulsed fiber laser options. Available in both OEM and Turnkey formats, our 1um and 1.5um fiber lasers are manufactured to Telcordia standards and can be modified to meet your applications requirements. With available average powers up to 10W at 1um and 1.5um, peak powers up to 25kW, pulse widths in the range of 200ps to 100ns, and available options such as pulse monitoring, internal and external triggering, TTL or LVDS input signals, extended operating temperature range, and a robust design, our pulse series of fiber lasers are suitable for a wide range of applications. Customized configurations are available upon request.
The neoMOS ultrashort pulse laser series is a reliable and low maintenance system designed for 24/7 industrial use. Its ultra-compact laser head has the smallest footprint available, making it easy to integrate into different systems. The laser systems are highly flexible and can be customized to meet specific needs, providing a wide range of laser parameters and pulse durations. With available pulse durations between 700fs and 70ps, repetition rates from single-shot to 80MHz, up to 500µJ pulse energy, average output powers up to 100W, multi-megawatt peak powers, and perfect TEM00 beam quality, these lasers can tackle many applications and are ideal for processing demanding materials such as transparent glasses and plastics.
The neoAMP series includes the neoVAN and neoYb DPSS laser amplifiers, designed to boost the average power or pulse energy for a wide range of applications. The flexible system design ensures a high degree of scalability, and the ultra-compact modules are easy to integrate into existing processing or scientific systems. The neoVAN and neoYb amplifiers are highly reliable and offer proven long-term stability, enabling a range of applications that include high peak power, short pulse picosecond lasers for micromachining, or single-frequency radiation for gravitational wave detection.
The NPS series of ultrafast lasers is the ultimate solution for OEM integrators and researchers working with nonlinear optics applications like OPO pumping and narrowband Raman spectroscopy. The NPS series boasts remarkable features such as up to 10W average output power, <7ps pulse width, and a 40MHz repetition rate. The transform-limited operation, with a spectral width of <0.3nm, and accurate central wavelengths make these lasers a suitable candidate for highly efficient amplification by Nd-doped DPSS amplifiers.
The Microchip series is a line of ultra-compact, passively q-switched, single longitudinal mode (SLM), narrow linewidth, DPSS lasers that offer exceptional performance in a compact form factor. The lasers feature pulse durations ranging from 400 ps to 2 ns, energy levels up to 80 µJ, and repetition rates up to 100 kHz. Available in wavelengths from the UV to the NIR, this series is designed for OEM integrators and researchers working with LIDAR, 3D scanning, LIBS, night vision, and more. The lasers offer both nanosecond and picosecond options and are interchangeable with the same form factor and electrical and software interfaces across wavelengths, making them a flexible and versatile solution.
The VaryDisk Series is a versatile and fully functional family of thin disk laser systems, providing high pulse energies at high average powers, suitable for laboratory investigations or industrial use. These thin disk regenerative amplifiers provide a range of beam parameters, depending on the configuration and your specific application needs. With a range of output specifications to choose from, including multiple seed lasers, customers can select the ideal configuration to meet their needs with many customization options available. The base configurations offer options for pulse widths in the fs, ps, and ns range, up to 1000 W average power, up to 150 mJ pulse energy, 1 kHz to 125 kHz rep. rate, and 1030 nm, 515 nm (SHG), and 343 nm (THG) wavelength options.
The Vento series is a compact and ruggedized sub-nanosecond DPSS laser series designed for OEM integrators, application specialists, and researchers working with scientific and industrial applications such as precision LIDAR and materials processing. With pulse durations down to 500 ps and repetition rates up to 200 kHz, this laser series produces high average power of up to 25 W @ 532 nm and up to 40 W @ 1064 nm. The Vento series features beam expanding and collimating optics, low jitter option, extended operating temperature range, pulse energy modulation up to IP68 Package, circular polarization, remote control cbox and software interface, air and water-cooled options, and AC-DC power supply.
The Wedge series is a line of DPSS lasers designed specifically for OEM applications such as micro machining of hard and soft materials, specialty marking, glass and crystal engraving, LIDAR, LIBS, spectroscopy, and medical diagnostics. Thesediode–pumped lasers, based on proprietary fast Q-switching technology, are compact, sealed, and monolithic which makes them insensitive to vibrations and harsh environments. With high peak powers and relatively low energy and heat generation, they allow efficient ablation and non-linear interaction with most materials. The compact and lightweight package is a great benefit in LIDAR and other aerospace applications, while short pulses provide extremely precise time-of-flight measurements.
