976nm IR laser diodes and IR laser modules are available with both single-mode and multi-mode beam profiles. They have either free space or fiber coupled outputs.
The diode laser packages are ideal for OEM applications, and laser modules are available for either OEM or plug and play applications.
|Picture||Part Number||Type||Output power (W)||Mode||Output||Linewidth||Pulse energy (uJ)||Pulse width||Rep rate|
|JDL-976||Array (Bar)||60.0, 80.0, 120.0||Multimode||Free Space|
|JDL-BAB-20-47-976-TE-80-2.0-LAR||Array (Bar)||80.0||Multimode||Free Space|
|JOLD-FC-976||Array (Bar)||30.0, 45.0, 75.0, 100.0, 120.0, 140.0, 210.0, 250.0, 400.0||Multimode||MM Fiber|
|JOLD-Open-976-CW||Array (Bar)||40.0, 50.0, 60.0, 80.0, 100.0, 120.0, 160.0, 275.0||Multimode||Free Space|
|JOLD-Open-976-CW-FAC||Array (Bar)||35.0, 55.0, 90.0||Multimode||Free Space|
|JOLD-Open-976-CW-FAC/SAC||Array (Bar)||32.0, 35.0, 50.0, 68.0||Multimode||Free Space|
|R0976||LD Module, Single Emitter, Volume Bragg Grating (VBG) Laser Diodes||0.150, 0.220, 0.450, 0.500, 0.600, 0.700, 0.800, 1.5, 4.0, 5.0||Single-Mode Lasers, Multimode||Free Space, MM Fiber, PM Fiber||Narrow|
|RBDL-CW-9XX||Turn-Key System||1000.0, 2000.0, 3000.0||Multimode||MM Fiber|
|RPK976M||Multi-Emitter||15.0, 20.0, 30.0, 70.0, 150.0, 200.0, 330.0, 540.0||Multimode||MM Fiber|
|RPK976MS||Multi-Emitter, Volume Bragg Grating (VBG) Laser Diodes||18.0, 27.0, 60.0, 100.0, 140.0, 180.0, 400.0||Multimode||MM Fiber||Narrow|
|RPK976S||Single Emitter||10.0||Multimode||MM Fiber|
|RPK976SS||Single Emitter, Volume Bragg Grating (VBG) Laser Diodes||3.0, 9.0||Multimode||MM Fiber||Narrow|
The JDL series of high-power laser bars are industry-leading and designed for a variety of optical pumping and DDL applications in materials processing, medicine, and sensing. Our unmounted laser bars offer a wide range of emitter configurations, cavity lengths, and operational modes up to 500 W. Our diode laser stacks can scale power into the multikilowatt range. We focus on delivering the highest-quality laser solutions with a commitment to reducing cost of ownership for our customers.
The JOLD-FC series of high-power diode lasers and fiber-coupled modules are fully customizable and available at various levels of integration, providing a cost-effective solution for OEM applications. With superior reliability and electro-optical efficiency, our lasers offer industry-leading performance. Our commitment to quality is reflected in our clearly defined production processes and certifications, which ensure that our solutions are both precise and productive, while minimizing waste and risks.
We offer standard wavelengths of 808 nm, 940 nm and 980 nm. The fiber core diameter of our diode lasers is 200 µm, 400 µm or 600 µm. On request, we will be happy to adapt the parameters to your individual requirements. You can also choose between pilot lasers, monitor diodes and integrated Peltier elements.
The JOLD-Open Heatsinks Series offers industry-leading performance for mounted diode lasers. Our proprietary heat sink and assembly technology, paired with our focus on advanced optical pumping and direct-diode-laser technology, results in diode lasers with unmatched performance. We’ve pioneered high-power diode laser assembly in high-volume manufacturing and tailored our laser bars to specific heat sink technology and operating modes. With reliable, cost-effective solutions, JOLD-Open Heatsinks is the clear choice for diode laser technology.
The R series of wavelength stabilized single–mode and multimode laser diodes offer narrow linewidth output in wavelengths from 633nm thru 1064nm. This highly customizable series offers package options ranging from components as basic as a TO-56 or 14-pin BF packaged diodes, to OEM modules including electronics, to UL/CE and IEC certified turn-key systems. The R series is the perfect source for various markets, including chemical analysis, bio-medical, fiber laser, and scientific applications.
The RBDL Series is a high–power direct diode turn-key system available in wavelengths of 445nm, 915nm or 976nm, providing up to 3kW of power and unprecedented brightness. With its pluggable design, maintenance is made easy, avoiding various troubles and high time costs caused by return-to-factory maintenance. The RBDL series is the result of continuous innovation, ensuring a high level of technical strength and product quality. Customizable options allow for you to find the product you need, while micro-optics transform the asymmetric beam out of the laser chip, improving the beam quality to couple the laser into small core fiber optics.
The RPK Series of multiple, single-emitter fiber-coupled diode lasers are available in wavelengths from 405nm thru 1550nm with up to 300W output power. Our specialized fiber-coupling techniques ensure high efficiency, stability, and superior beam quality, while rigorous inspections and burn-in procedures guarantee each product’s reliability, stability, and long lifetime. Highly customizable packages allow us to meet our customers’ specific needs, providing high-quality products at reasonable prices.
