213nm Lasers, specifically Diode-Pumped Solid-State (DPSS) Lasers, utilize fifth harmonic generation of Nd:YLF laser material at 1053nm. Given a particular laser, with a particular fundamental wavelength, fifth harmonic generation is less efficient and cannot achieve the same energy levels compared to its lower-order harmonic counterparts.
These high power, nanosecond 213nm lasers are available with either free-space or fiber-coupled output and a variety of pulse energies depending on the applications needs. Typical applications for these UV Lasers include Optogenetics, Laser Induced Breakdown Spectroscopy, Time-of-Flight Spectroscopy, Photoluminescence, and more.
Picture | Part Number | Type | Wavelength (nm) | Output power (W) | Pulse energy (uJ) | Pulse width | Rep rate |
---|---|---|---|---|---|---|---|
|
Quantas-Q1-213 | Pulsed DPSS Lasers | 213 | 0.005, 0.010, 0.020, 0.025 | 500.0, 1000.0, 2000.0, 2500.0 | 7ns, 8ns | 10Hz |
|
Quantas-Q2-213 | Pulsed DPSS Lasers | 213 | 0.004, 0.010, 0.020, 0.040, 0.050 | 400.0, 1000.0, 2000.0, 4000.0, 5000.0 | 5ns, 7ns, 8ns | 10Hz |
|
Quantas-Q2HE-213 | Pulsed DPSS Lasers | 213 | 0.040, 0.070, 0.075, 0.150 | 1500.0, 3000.0, 3500.0, 4000.0 | 6ns | 10Hz, 20Hz, 50Hz, 100Hz |
The Q1 series is a compact, energy-efficient, diode pumped, air-cooled, Q-switched laser available at 1064 and 1053nm with up to 45 mJ of pulse energy and rep rates up to 50Hz. The high peak powers and low divergence of the Q1 series enable efficient harmonic conversion through the 5th harmonic (213 or 211nm). The innovative design results in a user-friendly, turnkey system that requires little maintenance, and the laser’s variable pulse repetition rate and built-in sync pulse generator provide flexibility for triggering user equipment.
The Q2 series is a diode-pumped, fully air-cooled, Q-switched laser designed for a wide range of applications that require high peak power pulses. Its innovative water-free laser crystal end-pumping technology produces Gaussian-like, low divergence laser beams with high peak powers, allowing for efficient harmonics conversion through the 5th harmonic. This versatile platform can be configured in many ways, including up to 80mJ pulse energy at 10 Hz pulse repetition rate or up to 20mJ at 100 Hz. The laser can emit either 1053 nm or 1064 nm wavelength, and in the short cavity configuration, pulse duration can be reduced by 50% in comparison to standard configuration.
The Q2HE series is a high–energy, q-switched, diode-pumped solid-state (DPSS) laser series, available in either 1053nm or 1064nm fundamental wavelengths, with optional 2nd, 3rd, 4th, or 5th harmonic generation. This air-cooled series of lasers is designed for a wide range of applications that require high peak power pulses. Due to a short laser cavity, excellent thermal properties of the crystal, and an innovative water-free crystal cooling technology, the Q2HE series can deliver up to 120mJ of pulse energy and/or up to 4W average output power. This advanced laser design results in a compact, user-friendly turnkey system that requires little maintenance.
