Laser Diode Modules

What are Laser Diode Modules?

Laser Diode Modules (LD Modules) are complete packages with the laser diode, lensing, thermal management, and electrical interface all integrated into a compact OEM or plug & play style housing.

Have questions?

Get Answers

Learn more about Laser Diode Modules

Our CW laser diode (LD) modules include the laser diode with the thermal management and electrical interface. These simple, easy to use modules are available in either OEM or plug & play configurations.  They are available in the UV, Violet, Blue, Green, Red, NIR, SWIR, MWIR, and LWIR wavelength regimes. Furthermore, typical output powers range from milliwatts up to several watts.  Finally, other options include narrow linewidth & broadband options, both single-mode & multimode, free-space & fiber-coupled output, and line module versions.

Our modules are used in industrial, medical, and scientific industries. For example, applications include flow cytometry, DNA sequencing, confocal fluorescence microscopy, optogenetics, laser doppler velocimetry, particle measurement, holography, interferometry, Raman spectroscopy, and many more!



What can we do for you?

How Can We Help?

RPMC Lasers is your Laser Diode Module Supplier. We provide industry-leading CW Laser Diode Modules in many wavelengths for many industries.

With over 25 years experience matching the right laser source to your application, and our wide range of industry-leading LD module options, the team at RPMC is prepared and eager to help you find the right solution!

If you have any questions, or if you would like some assistance please Contact Us here. Furthermore, you can email us at [email protected] to talk to a knowledgeable Product Manager.

Alternatively, use the filters on this page to assist in narrowing down the selection of LD modules for sale. Finally, head to our Knowledge Center with our Lasers 101 page and Blogs, Whitepapers, and FAQ pages for further, in-depth reading.

Check out our Online Store: This page contains In-Stock products and an ever-changing assortment of various types of new lasers at marked-down/discount prices.



Additional Resources

Whitepapers:

Blogs:

Videos:

Continue reading
Show less
Filters Reset

Wavelength Selection

Power Selection

Mode

Output

Linewidth

Series

more more
Picture Part Number Wavelength (nm) Output power (W) Mode Output Linewidth Coherence length
1310L-1XA 1310 0.180 Single-Mode, Multimode PM Fiber, Free Space
1550L-1XA 1550 0.250, 0.300 Single-Mode PM Fiber, SM Fiber, Free Space
405L-1XA: 405nm Laser (Diode; MATCHBOX 2) 405L-1XA 405 0.100, 0.150, 0.180 Single-Mode PM Fiber, SM Fiber, MM Fiber, Free Space
IO Matchbox 405nm Laser 405L-2XA 405 0.020, 0.040, 0.050 Single-Mode PM Fiber, SM Fiber, MM Fiber, Free Space Narrow More than 1m
450L-3XA: 450nm Laser (HP MM Diode; MATCHBOX 2) 450L-1XA 450 0.035, 0.050, 0.060 Single-Mode PM Fiber, SM Fiber, MM Fiber, Free Space
450L-3XA: 450nm Laser (HP MM Diode; MATCHBOX 2) 450L-3XA 450 0.300, 0.400 Multimode MM Fiber, Free Space
488L-1XA: 488nm Laser (Diode; MATCHBOX 2) 488L-1XA 488 0.020, 0.030, 0.040 Single-Mode PM Fiber, SM Fiber, MM Fiber, Free Space
488L-2XA: 488nm SLM Laser (VBG Diode; MATCHBOX 2) 488L-2XA 488 0.010, 0.015, 0.030 Single-Mode PM Fiber, SM Fiber, MM Fiber, Free Space Narrow More than 1m
505L-1XA 505 0.030, 0.060 Single-Mode PM Fiber, SM Fiber, MM Fiber, Free Space
520L-1XA: 520nm Laser (Diode; MATCHBOX 2) 520L-1XA 520 0.050, 0.080, 0.090, 0.100 Single-Mode PM Fiber, SM Fiber, MM Fiber, Free Space
520L-2XA: 520nm SLM Laser (VBG Diode; MATCHBOX 2) 520L-2XA 520 0.025, 0.035, 0.040 Single-Mode PM Fiber, SM Fiber, MM Fiber, Free Space Narrow More than 1m
633L-2XA: 633nm SLM Laser (VBG Diode; MATCHBOX 2) 633L-1XA 633 0.035, 0.060, 0.080, 0.090 Single-Mode PM Fiber, SM Fiber, MM Fiber, Free Space
633L-2XA: 633nm SLM Laser (VBG Diode; MATCHBOX 2) 633L-2XA 633 0.035, 0.040, 0.070 Single-Mode PM Fiber, SM Fiber, MM Fiber, Free Space Narrow More than 1m
638L-1XA: 638nm Laser (Diode; MATCHBOX 2) 638L-1XA 638 0.100, 0.120, 0.170 Single-Mode PM Fiber, SM Fiber, MM Fiber, Free Space
638L-2XA: 638nm SLM Laser (VBG Diode; MATCHBOX 2) 638L-2XA 638 0.060, 0.080, 0.100 Single-Mode PM Fiber, SM Fiber, MM Fiber, Free Space Narrow More than 1m
638L-1XA: 638nm Laser (Diode; MATCHBOX 2) 638L-3XA 638 0.500, 0.600 Multimode MM Fiber, Free Space
638L-2XA: 638nm SLM Laser (VBG Diode; MATCHBOX 2) 638L-4XA 638 0.300, 0.500 Multimode MM Fiber, Free Space Narrow More than 1m
660L-1XA: 660nm Laser (Diode; MATCHBOX 2) 660L-1XA 660 0.060, 0.080, 0.090, 0.110 Single-Mode PM Fiber, SM Fiber, MM Fiber, Free Space
783L-2XA: 783nm SLM Laser (VBG Diode; MATCHBOX 2) 783L-2XA 783 0.070, 0.080, 0.110 Single-Mode PM Fiber, SM Fiber, MM Fiber, Free Space Narrow More than 1m
785L-1XA: 785nm Laser (Diode; MATCHBOX 2) 785L-1XA 785 0.120, 0.150, 0.170 Single-Mode PM Fiber, SM Fiber, MM Fiber, Free Space
785L-2XA: 785nm SLM Laser (VBG Diode; MATCHBOX 2) 785L-2XA 785 0.080, 0.100, 0.130 Single-Mode PM Fiber, SM Fiber, MM Fiber, Free Space Narrow More than 1m
785L-3XA: 785nm Laser (HP Diode; MATCHBOX 2) 785L-3XA 785 1.0 Multimode MM Fiber, Free Space
785L-4XA: 785nm Laser (HP VBG Diode; MATCHBOX 2) 785L-4XA 785 0.500, 0.700, 0.800 Multimode MM Fiber, Free Space Narrow More than 1m
ultra-compact, matchbook sized/shaped laser diode module 808L-1XA 808 0.055, 0.090, 0.110 Single-Mode PM Fiber, SM Fiber, MM Fiber, Free Space
ultra-compact, matchbook sized/shaped laser diode module 808L-3XA 808 1.6, 3.0 Multimode MM Fiber, Free Space
830L-1XA: 830nm Laser (Diode; MATCHBOX 2) 830L-1XA 830 0.070, 0.090, 0.130 Single-Mode PM Fiber, SM Fiber, MM Fiber, Free Space
830L-2XA: 830nm SLM Laser (VBG Diode; MATCHBOX 2) 830L-2XA 830 0.050, 0.070, 0.080 Single-Mode PM Fiber, SM Fiber, MM Fiber, Free Space Narrow More than 1m
830L-1XA: 830nm Laser (Diode; MATCHBOX 2) 830L-3XA 808 1.0 Multimode MM Fiber
850L-1XA: 850nm Laser (Diode; MATCHBOX 2) 850L-1XA 850 0.070, 0.110, 0.130 Single-Mode PM Fiber, SM Fiber, MM Fiber, Free Space
915L-1XA: 915nm Laser (Diode; MATCHBOX 2) 915L-1XA 915 0.080, 0.140, 0.170 Single-Mode PM Fiber, SM Fiber, MM Fiber, Free Space
975L-1XA: 975nm Laser (Diode; MATCHBOX 2) 975L-1XA 975 0.100, 0.140, 0.170 Single-Mode PM Fiber, SM Fiber, MM Fiber, Free Space
more more

Matchbox Series

R1Z4-Matchbox Laser

The Matchbox series offers excellent performance and reliability in the “World’s Smallest” ultra-compact, all-in-one, integrated laser head. They can operate on a 5V power supply while maintaining low noise operation. The monolithic design of the Matchbox Series laser includes thermally stabilized optics in a hermetically sealed housing, ensuring reliable and maintenance-free operation. This series is available in wavelengths from 405 nm thru 1064nm, with options for collimated beam or fiber-coupled output, and single-mode and multimode versions.

LaserBoxx Low Noise Series

The LaserBoxx Low Noise series of CW diode laser modules & DPSS lasers offer wavelengths from 375 to 1064nm, output powers up to 500 mW, and OEM & plug-&-play modules. These rugged, compact & highly customizable lasers also offer excellent beam quality & stability, modulation capabilities, ultra-low noise output & options for SM, MM, and PM fiber coupling. Our dedicated control software, USB and RS232 interfaces, and external controller with power display make integration, operation, and remote diagnostics a breeze.

LaserBoxx HPE Series

LBX-488

The LaserBoxx HPE Series is a highly versatile and customizable laser diode module series that offers superior performance and reliability in a compact, driver-integrated laser head. With a wide range of wavelengths from the UV to the NIR, this series provides high-power output, removable MM fiber coupling options & dedicated control software with USB and RS232 interfaces, as well as an external controller with power display, ensuring easy integration and precise power and modulation control.

LaserBoxx SLM Series

The LaserBoxx-SLM series of SLM CW DPSS & diode laser modules are available in wavelengths from 532-1064 nm, delivering ultra-narrow line widths with excellent temperature stability and low noise current. Embedded firmware locks the laser on the same mode at each startup. This customizable, compact laser module is available in turn-key or OEM versions, with GUI for remote operation & diagnostics via USB, RS232, or direct I/O interface, with modulation capabilities and adjustable power options.

R Series

R Series

The R series of wavelength-stabilized single-mode and multimode laser diodes offer narrow linewidth output in wavelengths from 633nm thru 1064nm, with output powers up to 5 W. This highly customizable series offers package options ranging from components as basic as a TO-56 or 14-pin BF packaged diodes to OEM modules, including electronics, to UL/CE and IEC-certified turn-key systems. The R series is the perfect source for various markets, including chemical analysis, bio-medical, fiber laser, and scientific applications.

REP Series

The REP series includes high-performance, tunable, single-frequency (DFB-like) diode lasers and Fabry-Perot laser diodes in wavelengths from 760nm thru 2350nm, designed to address challenges in Gas Sensing, LIDAR, Spectroscopy, and Telecom. The REP series includes high-power and narrow linewidth options, covering various product ranges at the most popular wavelengths, providing customizable units with multiple packaging options, including the Fiber coupled 14-pin butterfly, TO39 (w/TEC), and TO56.
