Collimated Beam Laser

What are Collimated Beam Lasers?

A collimated beam is a beam of light with parallel rays that spreads minimally as it travels. The rays in a collimated beam move in the same direction, without dispersing, and the beam’s energy is spread evenly along its path.
Collimated beams are useful in many industries, including engineering, scientific research, and medical applications.

In reality, no collimated beam has a perfectly constant diameter as it moves. The divergence of a collimated beam is the rate at which its diameter changes. The divergence depends on the light source and the collimator. To minimize divergence, you can increase the focal length of the collimating system or make the light source smaller. However, increasing the focal length means the system needs to be further from the source, which can decrease the beam’s power.

Part Number	Wavelength (nm)	Description	Type
JenLas D2	532, 1064	DPSS Laser, Multimode, Thin-disk, 532nm or 1064nm, up to 8W	CW DPSS Lasers, Collimated Beam, Fiber-Coupled, Customizable
LGK-XXX	543, 594, 633	He-Ne Laser Module, Single mode, 543-633nm, up to 20mW	HeNe Lasers, Narrow Linewidth, Long Coherence Length, Single Longitudinal Mode (SLM), Collimated Beam, Fiber-Coupled
LGR-XXX	543, 594, 633	He-Ne Laser Replacement Tube, Single mode, 543-633nm, up to 20mW	HeNe Lasers, Narrow Linewidth, Long Coherence Length, Single Longitudinal Mode (SLM), Collimated Beam, Fiber-Coupled
LXC-Combiner	Multiple Wavelength Options	Laser Combiner, Single mode, up to 6 Wavelengths, 375-1064nm, up to 500mW	LD Module, CW DPSS Lasers, Narrow Linewidth, Long Coherence Length, Single Longitudinal Mode (SLM), Collimated Beam, Fiber-Coupled, Customizable
LXX-IR-HPE	750, 785, 830, 940	Laser Module, Multimode, Infrared, 785-940nm, up to 1W	LD Module, Collimated Beam, Fiber-Coupled, Customizable
LXX-IR-SLM	785, 830, 1064	Laser Module, Stabilized, Infrared, 785-1064nm, up to 300mW	LD Module, CW DPSS Lasers, Narrow Linewidth, Long Coherence Length, Single Longitudinal Mode (SLM), Collimated Beam, Fiber-Coupled, Customizable
LXX-IR-SM	785, 808, 830, 915, 980, 1064	Laser Module, Single mode, Infrared, 785-1064nm, up to 500mW	LD Module, CW DPSS Lasers, Collimated Beam, Fiber-Coupled, Customizable
LXX-UV-HPE	375	Laser Module, Multimode, Ultraviolet, 375nm, up to 200mW	LD Module, Collimated Beam, Fiber-Coupled, Customizable
LXX-UV-SM	375, 395	Laser Module, Single mode, Ultraviolet, 375-395nm, up to 120mW	LD Module, Collimated Beam, Fiber-Coupled, Customizable
LXX-VIS-HPE	405, 450, 473, 488, 520, 638, 750	Laser Module, Multimode, Visible, 405-750nm, up to 1.2W	LD Module, Collimated Beam, Fiber-Coupled, Customizable
LXX-VIS-SLM	532, 553, 561, 633	Laser Module, Stabilized, Visible, 532-633nm, up to 300mW	LD Module, CW DPSS Lasers, Narrow Linewidth, Long Coherence Length, Single Longitudinal Mode (SLM), Collimated Beam, Fiber-Coupled, Customizable
LXX-VIS-SM	405, 415, 445, 450, 458, 473, 488, 505, 515, 532, 553, 561, 607, 633, 638, 640, 642, 647, 660, 730	Laser Module, Single mode, Visible, 405-730nm, up to 500mW	LD Module, CW DPSS Lasers, Collimated Beam, Fiber-Coupled, Customizable
MB-Combiner	Multiple Wavelength Options	Laser Combiner, Multimode/Single mode, up to 4 Wavelengths, 405-850nm, up to 150mW	LD Module, Collimated Beam, Fiber-Coupled
MB-IR-MM	785, 808, 830	Laser Module, Multimode, Infrared, 785-1064nm, up to 3W	LD Module, Collimated Beam, Fiber-Coupled
MB-IR-SLM	785, 830, 1030, 1064	Laser Module, Stabilized, Infrared, 783-1064nm, up to 500mW	LD Module, CW DPSS Lasers, Narrow Linewidth, Long Coherence Length, Single Longitudinal Mode (SLM), Collimated Beam, Fiber-Coupled
MB-IR-SM	785, 808, 830, 850, 915, 975, 1064, 1123, 1310	Laser Module, Single mode, Infrared, 785-1310nm, up to 300mW	LD Module, CW DPSS Lasers, Collimated Beam, Fiber-Coupled
MB-VIS-MM	450, 638	Laser Module, Multimode, Visible, 450-638nm, up to 600mW	LD Module, Collimated Beam, Fiber-Coupled, Customizable
MB-VIS-SLM	405, 488, 520, 633	Laser Module, Stabilized, Visible, 405-633nm, up to 170mW	LD Module, CW DPSS Lasers, Narrow Linewidth, Long Coherence Length, Single Longitudinal Mode (SLM), Collimated Beam, Fiber-Coupled
MB-VIS-SM	405, 488, 505, 520, 633, 660	Laser Module, Single mode, Visible, 405-660nm, up to 200mW	LD Module, Collimated Beam, Fiber-Coupled

more more

Collimated Beam Laser Benefits

There are several benefits to using a collimated beam laser:

Reduced Divergence: The beam maintains a consistent diameter over long distances, which is crucial for applications requiring precise targeting and minimal spread.
Improved Focusability: Collimated beams can be focused more effectively, enhancing their utility in tasks like cutting, engraving, and medical procedures.
Consistent Beam Quality: The beam’s quality remains stable, which is important for scientific experiments and optical setups where consistent performance is needed.
Versatility: These beams are used in various fields, including telecommunications, laser machining, and even in everyday devices like laser pointers.
Ease of Integration: In laboratory settings, collimated beams simplify the alignment of optical components, making experimental setups more flexible and easier to manage.
