Ultraviolet Lasers: Pulsed, CW, and Laser Diodes

Image UV Ultraviolet Laser

What are Ultraviolet Lasers?

Ultraviolet lasers (UV lasers) emit UV laser light, typically in the range of 200 nm to 389 nm. UV lasers offer extremely high photon energy, which opens up a wide range of applications that visible and infrared laser sources can’t address. The most common UV laser sources are the third and fourth harmonics on Nd: YAG, providing 355 nm and 266 nm wavelengths, respectively. It’s important to point out that while 355 nm and 266 nm are the most common UV laser wavelengths, several other Nd: YAG lines can be frequency doubled and tripled, producing a large selection of alternate UV wavelengths. To achieve these higher-order harmonics, the electric field density of the laser must be extremely high. As a result, these lasers are primarily available with q-switching capability. Continuous-wave (CW) UV laser diodes are also available at 375 nm, with single-mode and multi-mode beam profiles and free-space or fiber-coupled outputs.

Our UV Laser Products

We offer many different laser types with UV output, including Single Emitter Laser Diodes, Laser Diode Modules, CW DPSS Lasers, Pulsed DPSS Lasers, Microchip Lasers, MIL-Spec Lasers, and Micromachining Systems. Our UV products are available with up to 20 W average power, options for single-mode or multimode, free-space or fiber-coupled output, and various packaging options and integration levels from component to OEM to turnkey systems.



Filters Reset

Type

Wavelength Selection

Power Selection

Energy Selection

Pulse Width Selection

Rep Rate Selection

Output

Mode

Linewidth

Series

Picture Part Number Type Wavelength (nm) Output power (W) Mode Output Linewidth Pulse energy (uJ) Pulse width Rep rate
320 NX CW DPSS Lasers 320 0.050, 0.100, 0.200 Single-Mode Lasers Free Space Narrow
349 NX CW DPSS Lasers 349 0.050, 0.100, 0.150, 0.200 Single-Mode Lasers Free Space Narrow
Aero-266 Pulsed DPSS Lasers 266 0.600 6000.0, 12000.0 20ns Single Shot to 50Hz, Single Shot to 100Hz
Aero-355 Pulsed DPSS Lasers 355, 355/532/1064 1.0 10000.0, 20000.0 20ns Single Shot to 50Hz, Single Shot to 100Hz
R0Z2-Image-Compact-Efficient-UV-Laser CEUV Series Pulsed DPSS Lasers 266, 355, 532, 1064 5.0, 10.0, 20.0 500.0, 1000.0, 2000.0 3ns 10kHz to 1MHz
HL375: 375nm Laser Diode HL375 Single Emitter 375 0.200 Multimode Free Space
LBX-375-HPE LD Module 375 0.200, 0.400 Multimode Free Space, MM Fiber
LBX-375 LD Module 375 0.070 Single-Mode Lasers Free Space, MM Fiber, SM Fiber, PM Fiber
LBX-395 LD Module 375 0.120 Single-Mode Lasers Free Space, MM Fiber, SM Fiber, PM Fiber
Onda 266nm Onda 266nm Pulsed DPSS Lasers 266 0.800 80.0 2ns - 6ns Single shot to 1kHz, Single shot to 50kHz
Onda 355nm Onda 355nm Pulsed DPSS Lasers 355 0.300 150.0 3ns Single shot to 2kHz
Q-TUNE tunable DPSS laser Q-TUNE Pulsed DPSS Lasers, Tunable Lasers Tunable 0.210 8000.0 5ns 10Hz, 33Hz, 100Hz
Q-Shift Series Quantas-Q-SHIFT-291 Pulsed DPSS Lasers 291 0.075, 0.120, 0.150 250.0, 500.0, 1000.0, 1500.0, 2000.0, 2500.0 2ns - 5ns 10Hz, 20Hz, 33Hz, 50Hz, 100Hz
Q-Shift Series Quantas-Q-SHIFT-294 Pulsed DPSS Lasers 294 0.075, 0.120, 0.150 250.0, 500.0, 1000.0, 1500.0, 2000.0, 2500.0 2ns - 5ns 10Hz, 20Hz, 33Hz, 50Hz, 100Hz
Q-Shift Series Quantas-Q-SHIFT-325 Pulsed DPSS Lasers 325 0.045, 0.072, 0.090 120.0, 250.0, 500.0, 750.0, 1000.0, 1300.0 2ns - 5ns 10Hz, 20Hz, 33Hz, 50Hz, 100Hz
Q-Shift Series Quantas-Q-SHIFT-329 Pulsed DPSS Lasers 329 0.045, 0.072, 0.090 120.0, 250.0, 500.0, 750.0, 1000.0, 1300.0 2ns - 5ns 10Hz, 20Hz, 33Hz, 50Hz, 100Hz
Q-Shift Series Quantas-Q-SHIFT-388 Pulsed DPSS Lasers 388 0.125, 0.200, 0.250 600.0, 1200.0, 2400.0, 3600.0, 4800.0, 6000.0 2ns - 5ns 10Hz, 20Hz, 33Hz, 50Hz, 100Hz
Q-Shift Series Quantas-Q-SHIFT-388 Pulsed DPSS Lasers 388 0.060, 0.096, 0.120 180.0, 360.0, 750.0, 1250.0, 1500.0, 1800.0 2ns - 5ns 10Hz, 20Hz, 33Hz, 50Hz, 100Hz
Q-Shift Series Quantas-Q-SHIFT-WXXXX Pulsed DPSS Lasers Multiple Wavelength Options Varies Varies 2ns - 5ns 100Hz
Quantas-Q-SPARK-266: High energy, compact, nanosecond, DPSS laser Quantas-Q-SPARK-266 Pulsed DPSS Lasers 266 0.010 1500.0 2ns 20Hz
Quantas-Q-SPARK-355: High energy, compact, nanosecond, DPSS laser Quantas-Q-SPARK-355 Pulsed DPSS Lasers 355 0.010 2500.0 2ns 20Hz
Quantas-Q1-211: High energy, compact, nanosecond, DPSS laser Quantas-Q1-211 Pulsed DPSS Lasers 211 0.005, 0.010, 0.020, 0.025 500.0, 1000.0, 2000.0, 2500.0 7ns, 8ns Single Shot to 10Hz
Quantas-Q1-213: High energy, compact, nanosecond, DPSS laser Quantas-Q1-213 Pulsed DPSS Lasers 213 0.005, 0.010, 0.020, 0.025 500.0, 1000.0, 2000.0, 2500.0 7ns, 8ns 10Hz
Quantas-Q1-263: High energy, compact, nanosecond, DPSS laser Quantas-Q1-263 Pulsed DPSS Lasers 263 0.015, 0.030, 0.050, 0.070 1500.0, 3000.0, 5000.0, 7000.0 7ns, 8ns Single Shot to 10Hz
Quantas-Q1-266: High energy, compact, nanosecond, DPSS laser Quantas-Q1-266 Pulsed DPSS Lasers 266 0.015, 0.030, 0.050, 0.070 1500.0, 3000.0, 5000.0, 7000.0 7ns, 8ns Single Shot to 10Hz
Quantas-Q1-351: High energy, compact, nanosecond, DPSS laser Quantas-Q1-351 Pulsed DPSS Lasers 355 0.030, 0.060, 0.100, 0.130 3000.0, 6000.0, 10000.0, 13000.0 7ns, 8ns Single Shot to 10Hz
Quantas-Q1-355: High energy, compact, nanosecond, DPSS laser Quantas-Q1-355 Pulsed DPSS Lasers 355 0.030, 0.060, 0.100, 0.130 3000.0, 6000.0, 10000.0, 13000.0 7ns, 8ns 10Hz
Quantas-Q2-211: High energy, compact, nanosecond, DPSS laser Quantas-Q2-211 Pulsed DPSS Lasers 211 0.004, 0.010, 0.020, 0.040, 0.050 400.0, 1000.0, 2000.0, 4000.0, 5000.0 5ns, 7ns, 8ns 10Hz
Quantas-Q2-213: High energy, compact, nanosecond, DPSS laser Quantas-Q2-213 Pulsed DPSS Lasers 213 0.004, 0.010, 0.020, 0.040, 0.050 400.0, 1000.0, 2000.0, 4000.0, 5000.0 5ns, 7ns, 8ns 10Hz
Quantas-Q2-263: High energy, compact, nanosecond, DPSS laser Quantas-Q2-263 Pulsed DPSS Lasers 263 0.012, 0.025, 0.050, 0.100, 0.120 1200.0, 2500.0, 5000.0, 10000.0, 12000.0 5ns, 7ns, 8ns 10Hz, 20Hz, 33.3Hz, 50Hz
Quantas-Q2-266: High energy, compact, nanosecond, DPSS laser Quantas-Q2-266 Pulsed DPSS Lasers 266 0.012, 0.025, 0.050, 0.100, 0.120 1200.0, 2500.0, 5000.0, 10000.0, 12000.0 5ns, 7ns, 8ns 20Hz, 33.3Hz, 50Hz, 100Hz, 200Hz
Quantas-Q2-351: High energy, compact, nanosecond, DPSS laser Quantas-Q2-351 Pulsed DPSS Lasers 351 0.024, 0.045, 0.090, 0.180, 0.240 2400.0, 4500.0, 9000.0, 18000.0, 24000.0 5ns, 7ns, 8ns 10Hz, 20Hz, 33.3Hz, 50Hz
Quantas-Q2-355: High energy, compact, nanosecond, DPSS laser Quantas-Q2-355 Pulsed DPSS Lasers 355 0.024, 0.045, 0.090, 0.180, 0.240 2400.0, 4500.0, 9000.0, 18000.0, 24000.0 5ns, 7ns, 8ns 10Hz
Quantas-Q2HE: High energy, compact, nanosecond, DPSS laser Quantas-Q2HE-211 Pulsed DPSS Lasers 211 0.050, 0.075, 0.080 1500.0, 4000.0, 5000.0 6ns 10Hz, 20Hz, 50Hz
Quantas-Q2HE-213: High energy, compact, nanosecond, DPSS laser Quantas-Q2HE-213 Pulsed DPSS Lasers 213 0.040, 0.070, 0.075, 0.150 1500.0, 3000.0, 3500.0, 4000.0 6ns 10Hz, 20Hz, 50Hz, 100Hz
Quantas-Q2HE-263: High energy, compact, nanosecond, DPSS laser Quantas-Q2HE-263 Pulsed DPSS Lasers 263 0.180, 0.250, 0.300 5000.0, 15000.0, 18000.0 6ns 10Hz, 20Hz, 50Hz
Quantas-Q2HE-266: High energy, compact, nanosecond, DPSS laser Quantas-Q2HE-266 Pulsed DPSS Lasers 266 0.600 5000.0, 10000.0 7ns 20Hz, 50Hz, 100Hz
Quantas-Q2HE-351: High energy, compact, nanosecond, DPSS laser Quantas-Q2HE-351 Pulsed DPSS Lasers 351 0.350, 0.600 12000.0, 30000.0, 35000.0 6ns 10Hz, 20Hz, 50Hz
Quantas-Q2HE-355: High energy, compact, nanosecond, DPSS laser Quantas-Q2HE-355 Pulsed DPSS Lasers 355 0.300, 0.500, 0.600, 1.0, 1.2 12000.0, 20000.0, 25000.0, 30000.0 6ns 10Hz, 20Hz, 50Hz, 100Hz
Quantas-Q2HE: High energy, compact, nanosecond, DPSS laser Quantas-Q2HE-XXX-XXXX Pulsed DPSS Lasers Multiple Wavelength Options Varies Varies Varies 100Hz
RWLP-375M Single Emitter 375 0.100 Multimode MM Fiber
RWLP-395M: 395nm Multimode Laser Diode RWLP-395M Single Emitter 395 0.200, 0.300 Multimode MM Fiber
Bright Microlaser Microchip SB1 Laser SB1-236.5 Pulsed DPSS Lasers, Microchip Lasers 236.5 0.001 0.200, 2.0 1.3ns 500Hz, 5kHz
Bright Microlaser Microchip SB1 Laser SB1-266 Pulsed DPSS Lasers, Microchip Lasers 266 0.002, 0.005 0.500, 1.0, 2.0 1.3ns 1kHz, 5kHz, 10kHz
Bright Microlaser Microchip SB1 Laser SB1-355 Pulsed DPSS Lasers, Microchip Lasers 355 0.010 Narrow 1.0 1.3ns 10kHz
SOL-355 Pulsed DPSS Lasers 355 4.0 650.0 15ns - 35ns Single Shot to 100kHz
Wedge-B-266 Wedge-HB/XB 266 Pulsed DPSS Lasers 266 0.300, 0.500 150.0, 500.0 1.5ns, 1.8ns Single shot to 2kHz
Wedge-B-355 Wedge-HB/XB 355 Pulsed DPSS Lasers 355 0.400, 0.600 200.0, 600.0 1.2ns, 1.5ns Single shot to 1kHz, Single shot to 2kHz
Wedge-F-266 Wedge-HF/XF 266 Pulsed DPSS Lasers 266 0.050, 0.180 5.0, 15.0 700ps - 1500ps, 400ps - 700ps 10kHz to 50kHz
Wedge-HF-355: 355nm compact nanosecond laser Wedge-HF/XF 355 Pulsed DPSS Lasers 355 0.800 40.0 500ps - 1ns 10kHz to 50kHz

Skylark Series

The Skylark series of ultrareliable, high performance, CW single-frequency lasers are available at a variety of wavelengths with high average powers, making them well suited for a variety of highly specialized scientific and industrial applications. BRaMMS Technology® enables superior performance, high output powers, and outstanding beam properties in an overall compact footprint. The Skylark series of lasers are utilized in a range of applications including holography, metrology, spectroscopy, and quantum technology.

Aero Series

Aero Laser by Bright SolutionsThe Aero Series is a high-energy DPSS laser that operates at less than 15 nanoseconds with multiple wavelength options including 266, 355, 532, and 1064nm. This series provides unparalleled precision and accuracy in even the most challenging environments. All models come enclosed in an extremely compact and ruggedized single unit with a conductively cooled heatsink with a water-cooled option. It comes with available options for beam expanding and collimating optics. This laser series is ideal for applications like LIBS, spectroscopy, and Atmospheric LIDAR.

CEUV Series

R0Z2-Image-Compact-Efficient-UV-LaserThe CEUV series is a commercial line of compact and efficient DPSS laser sources, capable of operating over a wide range of pulsing conditions (duty-cycle and PRF), in a low SWaP package, with average power up to ≈5W @ 266nm, 10W @ 355nm or 532nm, 20W @ 1064nm. This series of DPSS lasers provides a combination of compact, efficient, and high-power performance in a rugged design suitable for harsh environments and airborne applications. The design has been tested in brassboard hardware and a prototype is being developed.

HL Series

TG420

The HL Series offers versatile and high-quality laser diode products in a variety of wavelengths and high-power options, ideal for direct imaging, industrial, and bio/medical applications. These reliable, efficient, and compact diodes come in TO-Can packages, making them perfect for OEM integration. Additionally, they operate with TE mode oscillation and are RoHS compliant, ensuring safe use. Choose the HL Series for quality, reliability, and performance in laser diodes.

LaserBoxx HPE Series

LBX-488

The LaserBoxx HPE Series is a highly versatile and customizable laser module series that offers superior performance and reliability in a compact, driver integrated laser head. With a wide range of wavelengths from the UV to the NIR, this series offers high-power laser diode modules that are perfect for a variety of applications. The LaserBoxx HPE series also includes removable multimode fiber coupling options and dedicated control software with USB and RS232 interfaces, as well as an external controller with power display, ensuring easy integration and precise power and modulation control.

LaserBoxx Low Noise Series

The LaserBoxx Low Noise series of CW diode laser modules, with a variety of wavelengths from 375 to 785nm and output powers up to 350mW, offers highly customizable laser solutions for OEM and plug & play modules. With advanced features such as excellent beam quality, stability, and modulation capabilities, our lasers provide ultra-low noise and a wide range of options for SM, MM, and PM fiber coupling. Our dedicated control software, USB and RS232 interfaces, and external controller with power display make integration, operation, and remote diagnostics a breeze. Additionally, our rugged and compact design and wide variety of standard wavelengths ensure that our lasers can meet your specific needs.

Onda Series

Onda 532nm: 532nm High Energy Laser

The Onda series is a DPSS nanosecond OEM laser platform designed for high-end applications requiring excellent beam quality and high peak power in materials such as metals, glass, plastics, and various delicate and hard materials. This compact and easy to use laser series is available in wavelengths of 266, 355, 532, and 1064nm, with an extended operating temperature range and superior performance to cost ratio. The Onda seriesinternal optical layout and accurate temperature management enable high output energies without compromising the lifetime of the THG and FHG stages.

Q-TUNE Series

Q-TUNE-IR

The Q-TUNE series is a highly efficient, tunable wavelength laser designed for researchers working with temporally resolved spectroscopy, metrology, photo-acoustic imaging, and remote sensing applications. This laser uses an optical parametric oscillator (OPO) to produce a tunable wavelength range of 410-2300 nm with a linewidth narrower than 6 cm-1, which can be extended to 210-410 nm with an optional second harmonic generator. With a pulse duration shorter than 5ns and an upper repetition rate of 100Hz, the Q-TUNE series provides a perfect coherent light source for precise scientific measurements.

Q-SHIFT Series

Q-Shift SeriesThe Q-SHIFT series of Q-switched DPSS lasers is designed for researchers and application specialists working in micromachining, dermatology, LIDAR, time-resolved laser spectroscopy, and LIBS applications. With its built-in nonlinear wavelength conversion stage, this series allows the production of unconventional fundamental DPSS wavelengths, including 1163, 1177, 1300, 1317, 1551 and 1571 nm options, making it an ideal choice for those seeking wavelengths that are not accessible with conventional solid-state laser sources. With the optional harmonics generator, it is possible to generate up to the 4th harmonic for each fundamental wavelength, providing even more versatility.

Q-Spark

Quantas-Q-SPARK-266: High energy, compact, nanosecond, DPSS laser

The Q-SPARK series is an air-cooled, diode-pumped, Q-switched laser designed for researchers and application specialists working with ablation, LIDAR, remote sensing, and LIBS applications. The laser produces sub-nanosecond or nanosecond pulses with peak power up to 20 MW and pulse energies up to 10 mJ, making it ideal for a wide range of applications. With a short <1.5 ns pulse, compact air-cooled package, and innovative water-free laser crystal end-pumping technology, the Q-SPARK series delivers high-quality, low divergence, Gaussian-like laser beams.

Q1 Series

Quantas-Q1-211: High energy, compact, nanosecond, DPSS laser

The Q1 series is a compact, energy-efficient, diode pumped, air-cooled, Q-switched laser available at 1064 and 1053nm with up to 45 mJ of pulse energy and rep rates up to 50Hz. The high peak powers and low divergence of the Q1 series enable efficient harmonic conversion through the 5th harmonic (213 or 211nm). The innovative design results in a user-friendly, turnkey system that requires little maintenance, and the laser’s variable pulse repetition rate and built-in sync pulse generator provide flexibility for triggering user equipment.

Q2 Series

Quantas Q2 QLI

The Q2 series is a diode-pumped, fully air-cooled, Q-switched laser designed for a wide range of applications that require high peak power pulses. Its innovative water-free laser crystal end-pumping technology produces Gaussian-like, low divergence laser beams with high peak powers, allowing for efficient harmonics conversion through the 5th harmonic. This versatile platform can be configured in many ways, including up to 80mJ pulse energy at 10 Hz pulse repetition rate or up to 20mJ at 100 Hz. The laser can emit either 1053 nm or 1064 nm wavelength, and in the short cavity configuration, pulse duration can be reduced by 50% in comparison to standard configuration.

Q2HE Series

Quantas-Q2HE-211: High energy, compact, nanosecond, DPSS laser

The Q2HE series is a highenergy, q-switched, diode-pumped solid-state (DPSS) laser series, available in either 1053nm or 1064nm fundamental wavelengths, with optional 2nd, 3rd, 4th, or 5th harmonic generation. This air-cooled series of lasers is designed for a wide range of applications that require high peak power pulses. Due to a short laser cavity, excellent thermal properties of the crystal, and an innovative water-free crystal cooling technology, the Q2HE series can deliver up to 120mJ of pulse energy and/or up to 4W average output power. This advanced laser design results in a compact, user-friendly turnkey system that requires little maintenance.

RWLP Series

R3Z0-WSLP-905-050m-M-PD: 905nm Multimode Fiber Coupled Laser Diode

The RWLP series offers an affordable and versatile solution for your laser application needs with single-mode and multimode options and wavelengths from 405nm thru the IR region. With customizable options, our team can work with you to solve any challenges you may face. Rigorously tested for long-term reliability, the RWLP series ensures consistent performance and high beam quality. Perfect for integration, this series supports multiple applications including biological and analytical instrumentation.

Microchip Series

Bright Microlaser Microchip SB1 Laser

The Microchip series is a line of ultra-compact, passively q-switched, single longitudinal mode (SLM), narrow linewidth, DPSS lasers that offer exceptional performance in a compact form factor. The lasers feature pulse durations ranging from 400 ps to 2 ns, energy levels up to 80 µJ, and repetition rates up to 100 kHz. Available in wavelengths from the UV to the NIR, this series is designed for OEM integrators and researchers working with LIDAR, 3D scanning, LIBS, night vision, and more. The lasers offer both nanosecond and picosecond options and are interchangeable with the same form factor and electrical and software interfaces across wavelengths, making them a flexible and versatile solution.

SOL Series

SOL-03-532: 532nm Nanosecond Laser

The SOL series is the most compact, air-cooled, Q-switched DPSS nanosecond laser available in the power range from 4W to 40W @ 1064nm. Available @ 1064nm, 532nm, and 355nm, the SOL laser series offers excellent beam quality and high peak power, capable of up to 10W and 650µJ at 532nm and 4W @ 355nm, making it the ideal source for the most demanding industrial and scientific applications. With a rugged, compact, lightweight, and easy to use single unit design, the SOL laser is easy to integrate into micro-machining and marking applications, providing superior operational flexibility and performance/cost ratio.

Wedge Series

Wedge-XF-1064: 1064nm Picosecond Laser

The Wedge series is a line of DPSS lasers designed specifically for OEM applications such as micro machining of hard and soft materials, specialty marking, glass and crystal engraving, LIDAR, LIBS, spectroscopy, and medical diagnostics. These diodepumped lasers, based on proprietary fast Q-switching technology, are compact, sealed, and monolithic which makes them insensitive to vibrations and harsh environments. With high peak powers and relatively low energy and heat generation, they allow efficient ablation and non-linear interaction with most materials. The compact and lightweight package is a great benefit in LIDAR and other aerospace applications, while short pulses provide extremely precise time-of-flight measurements.
