JOLD-FC-808

Fiber Coupled Laser Diode Bar, 808nm, up to 400W, multimode

Key Features:

  • Center Wavelength: 808nm
  • High optical output power up to 400W
  • Fiber core diameter: 200/400/600µm – NA 0.22 | 800µm – NA 0.14
  • Integrated pilot laser / power monitor / fiber detector (per configuration)
  • Passive cooling* – Conductive / water / air / integrated TEC (per configuration)
  • *Fiber-coupled Stack configurations – Actively cooled with deionized water



There are many configurations and options available. If you do not see exactly what you need below, please contact us!

Need Quantities?  Use Get Quote to get volume pricing!

POPULAR CONFIGURATIONS:

Part Number
Part Description
Datasheet
Price
Lead Time
Quantity

JOLD-100-FC-18-808-QCW

Fiber-Coupled Laser Diode, 808nm, 100W QCW, 800um, 0.14 NA MM Fiber, Conductive Cooling



In Stock

Get Quote
JOLD-3.5-BAXH-1E

Laser Diode Module 3.5 Watts: JO material 074243-010-24-808; PMS material #1000008643; Rev J



4-8 weeks

Get Quote
JOLD-4.2-BAXH-1E

Laser Diode Module 4.2 Watts; JO material 074243-009-24-808; PMS material #1000008668; Rev G



4-8 weeks

Get Quote
JOLD-30-CPXF-1L 808

Fiber-Coupled Laser Diode, 808nm, 30W, 400um, 0.22 NA MM Fiber, Integrated TEC



In Stock

Get Quote
JOLD-30-FC-14: Fiber Coupled Laser Diode JOLD-30-FC-12 808

Fiber-Coupled Laser Diode, 808nm, 30W, 200um, 0.22 NA MM Fiber, Conductive Cooling



4-8 weeks

Get Quote
JOLD-30-FC-14: Fiber Coupled Laser Diode JOLD-30-FC-14-808

Fiber-Coupled Laser Diode, 808nm, 30W, 400um, 0.22 NA MM Fiber, Conductive Cooling



In Stock

Get Quote
JOLD-30-FCM-12 808 JOLD-30-FCM-12 808

Fiber-Coupled Laser Diode, 808nm, 30W, 200um, 0.22 NA MM Fiber, Conductive Cooling



4-8 weeks

Get Quote
JOLD-30-FC-18-808

Semiconductor Laser Diode, 30W CW output Power, ,SMA connector for 800 micron fiber coupled output of .14NA, 809nm +/- 2nm at 25C

$1,250.00
Get Quote
JOLD-45-CPXF-1L JOLD-45-CPXF-1L 808

Fiber-Coupled Laser Diode, 808nm, 45W, 400um, 0.22 NA MM Fiber, Integrated TEC



4-8 weeks

Get Quote
JOLD-70-QPXF-1L 808

Fiber-Coupled Laser Diode, 808nm, 70W QCW, 600um, 0.22 NA MM Fiber, Integrated TEC



4-8 weeks

Get Quote
JOLD-75-CPXF-2P-W JOLD-75-CPXF-2P 0.6 W 808

Fiber-Coupled Laser Diode, 808nm, 75W, 600um, 0.22 NA MM Fiber, Water Cooling



In Stock

Get Quote
JOLD-75-CPXF-2P iTEC 808

Fiber-Coupled Laser Diode, 808nm, 75W, 600um, 0.22 NA MM Fiber, Integrated TEC



4-8 weeks

Get Quote
JOLD-75-CPXF-2P-W JOLD-75-CPXF-2P W 808

Fiber-Coupled Laser Diode, 808nm, 75W, 400um, 0.22 NA MM Fiber, Water Cooling



4-8 weeks

Get Quote
JOLD-100-CPXF-2P-W: Fiber Coupled Laser Diode JOLD-100-CPXF-2P W 808

Fiber-Coupled Laser Diode, 808nm, 100W, 400um, 0.22 NA MM Fiber, Water Cooling



4-8 weeks

Get Quote
JOLD-120-QPXF-2P-iTEC: Fiber Coupled Laser Diode JOLD-120-QPXF-2P iTEC 808

Fiber-Coupled Laser Diode, 808nm, 120W QCW, 600um, 0.22 NA MM Fiber, Integrated TEC



4-8 weeks

Get Quote
JOLD-120-QPXF-2P-W: Fiber Coupled Laser Diode JOLD-120-QPXF-2P W 808

Fiber-Coupled Laser Diode, 808nm, 120W QCW, 600um, 0.22 NA MM Fiber, Water Cooling



3-6 weeks

Get Quote
JOLD-140-CAXF-6A 808 JOLD-140-CAXF-6A 808

Fiber-Coupled Laser Diode, 808nm, 140W, 600um, 0.22 NA MM Fiber, Active – DI Water Cooling



3-6 weeks

Get Quote
JOLD-210-CAXF-6A 808 JOLD-210-CAXF-6A 808

Fiber-Coupled Laser Diode, 808nm, 210W, 600um, 0.22 NA MM Fiber, Active – DI Water Cooling



4-8 weeks

Get Quote
JOLD-250-CAXF-6P2: Fiber Coupled Laser Diode JOLD-250-CAXF-6P2 808

Fiber-Coupled Laser Diode, 808nm, 250W, 600um, 0.22 NA MM Fiber, Active – DI Water Cooling



4-8 weeks

Get Quote
JOLD-400-CAXF-6P2 915 JOLD-400-CAXF-6P2 808

Fiber-Coupled Laser Diode, 808nm, 400W, 600um, 0.22 NA MM Fiber, Active – DI Water Cooling



4-8 weeks

Get Quote

The JOLD-FC-808 is an 808nm, multimode, fiber-coupled, laser diode array, with up to 400W output power. Depending on the specific configuration, these laser diode modules offer either CW or QCW output, a pilot laser, power monitor, and/or fiber detector, 200/400/600µm core fiber with 0.22 NA, or 800µm core with 0.14 NA with free-standing SMA 905 connector. The JOLD-FC-808 Array configurations are passively cooled either conductively, by tap water or air cooling, or by an integrated TEC. JOLD-FC-808 Stack configurations are actively cooled with deionized water.

Type

Wavelength (nm)

Output power (W)

, , , , , , , , ,

Mode

Output

Duty

,

Package
