Bright Microlaser

Bright Microlaser Overview

Bright Microlaser, a member of the Bright Solutions Group, is focused on the development and manufacturing of advanced DPSS Microchip lasers. The company leverages their years of in-house experience on passively q-switched lasers, as well as the technology and factory assets acquired from Concepts Research Corporation, formerly a leading US manufacturer of microchip lasers. Bright Microlaser is continuously advancing the microchip laser technology by developing new enhancements, packages, driver functionalities, and wavelength configurations required to meet the growing industry demands.



In addition to bringing outstanding products to the market, Bright Microlaser is committed to offering a world-class level of quality, customer care and service with their ultra-compact passively q-switched DPSS Microchip Lasers. For pulsed laser applications where size, ruggedness, portability and performance are key, such as 3D scanning, LIDAR, LIBs, and airborne or space applications, the compact, conductively cooled, BrightMicroLaser Microchip Laser series is the ideal solution.



The Bright Solutions Group consists of 4 business units: Bright Solutions, Bright Microlaser, Bright Systems, and Bright Aerospace.

Type

Wavelength Selection

Power Selection

Energy Selection

Pulse Width Selection

Rep Rate Selection

Series

Manufacturer

28 results found
Picture Part Number Type Wavelength (nm) Output Power (W) Mode Output Narrow Linewidth Pulse Energy (uJ) Pulse Width Rep Rate
FP3-1064-15-15: 1064nm microchip lasers FP3-1064-15-15 Microchip Lasers 1064 0.225 15.0 1.3ns 15kHz
FP3-1064-2-100: 1064nm microchip laser FP3-1064-2-100 Microchip Lasers 1064 0.200 2.0 470ps 100kHz
FP3-1064-2-55: 1064nm microchip laser FP3-1064-2-55 Microchip Lasers 1064 0.110 2.0 470ps 55kHz
FP3-1064-20-10: 1064nm microchip laser FP3-1064-20-10 Microchip Lasers 1064 0.200 20.0 1.3ns 10kHz
FP3-1064-30-5: 1064nm microchip laser FP3-1064-30-5 Microchip Lasers 1064 0.150 30.0 1.3ns 5kHz
FP3-1064-40-1: 1064nm microchip laser FP3-1064-40-1 Microchip Lasers 1064 0.040 40.0 1.3ns 1kHz
FP3-1064-60-0.2: 1064nm Microchip Laser FP3-1064-60-0.2 Microchip Lasers 1064 0.060 60.0 1.3ns 200Hz
FP3-1064-80-0.1: 1064nm Microchip Laser FP3-1064-80-0.1 Microchip Lasers 1064 0.080 80.0 1.3ns 100Hz
FP3-473-1-10: 473nm Microchip Laser FP3-473-1-10 Microchip Lasers 473 0.010 1.0 2ns 10kHz
FP3-473-3-5: 473nm microchip laser FP3-473-3-5 Microchip Lasers 473 0.015 3.0 2.5ns 5kHz

Microchip Series

Microchip Series by BrightMicrolaser

The Microchip Series, available in the FP3 and P4 packages from BrightMicroLaser, are ultra-compact, passively q-switched DPSS lasers that feature pulse durations from 350 ps to 3 ns, energy levels up to 100 uJ and repetition rates up to 100 kHz. In addition to the fundamental 1064 nm wavelength and its harmonics (532, 355 and 266 nm), we also deliver units emitting at 946 and 473 nm.
